Note: The method of manual override can either be selected to operate from the valet switch or operate as
custom code. Be certain to place a check mark indicating the method used in the box located on
the last page of the owner's manual.
Note: When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door
pin switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1 Chirp
1st Door L/UL
1 Sec.
2nd Accy Lock
Auto Lock On
3rd Accy. UL
Auto UL Dr
4th Headlights
On Arm
5th Passive Locks
Passive
6th Passive/Active Arm
Passive Arm
7th Voltage Sense
Voltage Sense
8th Siren/Horn
Siren/Horn
9th Horn Chirp
10mS
10th Override Method
Custom Code
11th Two Step Unlock
On
12th Chirp Del From Tx
On
To program these selectable features;
Action
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Second Press and release the valet switch
Press transmitter Lock button to change
or
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Press transmitter Lock button to change
SELECTABLE FEATURES
2 Chirps
3 Chirps
3.5 Sec.
1 S L, Dbl.U/L
Auto Lock Off
Auto UL All
Auto UL Off
On Disarm
On Both
Active
Active Arm
Hardwire
Siren Only
Horn Only
16mS
30mS
Valet
O f f
O f f
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
4 chirps = 350mS unlock 1 second lock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock drivers door only
2 chirps = auto unlock all doors
3 chirps = headlight output when arming and disarming
4 chirps = headlight output off
1 chirp = headlight output when arming
2 chirps = headlight output when disarming
Page 1
Model PRO 9644N
Installation Manual
4 Chirps
5 Chirps
350mS UL/1SL
O f f
40mS
50mS
System Response
Default
1 Sec.
Auto Lock Off
Auto UL Off
Both
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
O f f
O f f
128-8501
1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox PRO 9644N
Summary of Contents for Audiovox PRO 9644N
- Page 1 Model PRO 9644N Installation Manual SELECTABLE FEATURES Note: The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
- Page 2 Fifth Press and release the valet switch 2 chirps = active locks Press transmitter Lock button to change 1 chirp = passive locks Sixth Press and release the valet switch 2 chirps = active arming Press transmitter Lock button to change 1 chirp = passive arming Seventh Press and release the valet switch 2 chirps = hardwire...
- Page 3 Note: This is a normally closed starter cut arrangement, and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.
- Page 4 Note: This is a normally opened starter cut arrangement, and when power is removed from the security system, the starter disable feature will remain operational, and the vehicle will not start. Audiovox does not recommend using the Orange w/ White trace wire to interrupt anything but the starting circuit of the vehicle.
- Page 5 CAUTION: Do not use the brown wire if the vehicle has + 12 volt output type door switches. (See Purple Wire). Note for vehicles with interior delay lighting see programming under title "Completing The Installation". Purple Wire: + DOOR TRIGGER If the vehicle’s door courtesy light switches have a + 12 volt output when the door is opened (most Fords and some Imports), you must connect this wire to the positive output from one of the door switches.
- Page 6 3 Wire Ground Switched Single Step Door Locks In this application, the red wire provides a ground pulse during arming, or the pulsed ground lock output. Connect the red wire to the wire that provides a low current ground signal from the factory door lock switch to the factory door lock control relay.
- Page 7 These applications require the use of additional components which may include relays, fixed resistors, or for convenience, the AS 9159 Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supplement and or the Audiovox fax back service for information on your particular vehicle for properly connecting to these types of circuits.
- Page 8 © 2008 Audiovox Electronics Corp., Hauppauge, N.Y. 11788 128-8501 Page 8 128-8501 8 of 8...
