FORWARD

Thank you for choosing this Icom repeater. The IC-
FR5200H/IC-FR6200H
vhf
designed and built with Icom's state of the art technol-
ogy and craftsmanship. With proper care, this product
should provide you with years of trouble-free opera-
tion.
We want to take a couple of moments of your time to
thank you for making the IC-FR5200H/IC-FR6200H
your repeater of choice, and hope you agree with
Icom's philosophy of "technology first." Many hours
of research and development went into the design of
your IC-FR5200H/IC-FR6200H.
D FEATURES
m Built-in 5-Tone, DTMF encoder & decoder
Multiple signaling systems are equipped as stan-
dard. These systems are fully compatible with Icom
F-series radios.
m DTMF remote control capability
You can control the repeater from a remote location
over the air or over a phone line with DTMF.
m D-Sub 25 pin ACC port equipped
You can use the optional equipment via the D-sub
25 pin ACC port equipped on the repeater's rear
panel.
m Other features
- Wide frequency coverage
<VHF>
IC-FR5200H: 136 to 174 MHz
<UHF>
IC-FR6200H: 350 to 400 MHz,
400 to 470 MHz,
450 to 512 MHz,
450 to 520 MHz
- PC programmable
- 19 inch rack mount
- Optional Voice Scrambler Unit (UT-109R/
UT-110R) for base operating mode
Icom, Icom Inc. and the Icom logo are registered trademarks
of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other
countries.
All other products or brands are registered trademarks or
trademarks of their respective holders.
are
/
uhf fm repeaters

TABLE OF CONTENTS

IMPORTANT ............................................................... i
EXPLICIT DEFINITIONS ............................................ i
SUPPLIED ACCESSORIES....................................... i
PRECAUTIONS .......................................................... i
FORWARD ................................................................ ii
TABLE OF CONTENTS ............................................ ii
SAFETY TRAINING INFORMATION ....................... iii
1 PANEL DESCRIPTION ............................. 1-3
n Front panel ........................................................ 1
D Function display ............................................ 2
n Rear panel ......................................................... 2
D Accessory connector .................................... 3
2 INSTALLATION AND CONNECTIONS .... 4-6
n Unpacking ......................................................... 4
n Selecting a location ........................................... 4
n Antenna connection .......................................... 4
n Front panel connection ...................................... 5
n Rear panel connection ...................................... 5
n Power supply connection .................................. 6
n Mounting the repeater ....................................... 6
D Using the supplied handle ............................. 6
n Fuse replacement ............................................. 6
D Line fuse replacement ................................... 6
3 OPERATION ................................................. 7
n Receiving and transmitting ................................ 7
D Repeater operation ....................................... 7
D Base station operation .................................. 7
4 MAINTENANCE ............................................ 8
n Troubleshooting ................................................. 8
5 OPTIONS ...................................................... 9
6 INFORMATION ........................................... 10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
ii
