TBK vision RYK777F Instruction Manual

B/w 1/3” ccd camera
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
2004/02/02 Ver:1.0 No:040032/1
B/W 1/3" CCD CAMERA
I N S T R U C T I O N
M A N U A L
CONTENTS
1. Description ................................ 1
2. Main features ............................ 2
3. Cautions on handling ................ 2
5. Names of each part ................... 3

1. DESCRIPTION

Thank you very much for purchasing our product.
This Black and White Camera use high sensitive 1/3" interline
transfer CCD image Sensor (CCD = Charge Coupled Device), and
all state circuitry which provide extremely long life and high
reliability. This Camera offers excellent image quality with low lag
and high burn resistance, and is not subject to distortions from
magnetic fields. High resistance shock and vibration, easy to install,
this Camera is a very good choice for your B/W CCTV system.
Page
6. How to operate .......................... 4
7. Auto iris control ........................ 5
8. Packing ..................................... 5
9. Specifications ............................ 6
P.1
25
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RYK777F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TBK vision RYK777F

Summary of Contents for TBK vision RYK777F

  • Page 1: Table Of Contents

    2004/02/02 Ver:1.0 No:040032/1 B/W 1/3” CCD CAMERA I N S T R U C T I O N M A N U A L CONTENTS Page Page 1. Description ........ 1 6. How to operate ......4 2. Main features ......2 7.

  • Page 2: Main Features

    2. MAIN FEATURES B/W camera with SONY 1/3“ Super HAD CCD sensor in metal case. Pixel number: EIA=380,000 / CCIR=440,000 (High Resolution) EIA=270,000 / CCIR=320,000 (Normal Resolution) Reduced fixed pattern noise and lag. No sticking and no image distortion. Blooming suppression. Auto Electronic Shutter(AES),Auto Gain Control(AGC),Back Light Compensation(BLC),Line Lock(LL),Audio.

  • Page 3: Names Of Each Part

    5. NAMES OF EACH PART...

  • Page 4: How To Operate

    6. HOW TO OPERATE (1) Remove the cap cover from the top of the Lens Mount 1 . (2) If CS Mount Lens is used, remove the C Mount ring. (3) Screw the Lens into the Lens Mount. (4) Connect the Video Output 3 to the monitor or other video device through a 75 Ohms type coaxial cable.

  • Page 5: Auto Iris Control

    7. AUTO IRIS CONTROL CONNECTOR VIDEO DRIVER +12V DC IRIS OUT Video Driver Lens Connector 8. PACKING 1 Camera 1 C Mount ring 2 Screws 1 L Wrench 1 Connector 4 Pins for Auto Iris Lens 1 Instruction Manual...

  • Page 6: Specifications

    9.SPECIFICATIONS B/W Analog Type Model Type B/W 1/3” Exview CCD B/W 1/3” Exview CCD B/W 1/3” CCD High B/W 1/3” CCD Normal High Resolution Normal Resolution Resolution Resolution SONY 1/3” EXview SONY 1/3” EXview SONY 1/3” Super SONY 1/3” Super Image Pick-up Device HAD CCD sensor HAD CCD sensor...
