2004/08/02 Ver:1.0 No:040068/1
Mini DOME CCD CAMERA
I N S T R U C T I O N
This Instruction Manual applies to the following two
models: SURFACE TYPE
CONTENTS
IMPORTANT SAFETY GUARD AND WARNINGS........................2
DESCRIPTION.....................................................................2
INSTALLATION.....................................................................3
HOW TO OPERATE...............................................................5
SPECIFICATION...................................................................6
M A N U A L
IN-CEILING TYPE
P1
Page
Advertisement
Table of Contents
Related Manuals for TBK vision RYK2C54
Summary of Contents for TBK vision RYK2C54
-
Page 1: Table Of Contents
2004/08/02 Ver:1.0 No:040068/1 Mini DOME CCD CAMERA I N S T R U C T I O N M A N U A L This Instruction Manual applies to the following two models: SURFACE TYPE IN-CEILING TYPE CONTENTS Page IMPORTANT SAFETY GUARD AND WARNINGS……………………2 DESCRIPTION……………………………………………………………2 INSTALLATION…………………………………………………………...3 HOW TO OPERATE……………………………………………………...5... -
Page 2: Important Safety Guard And Warnings
Important Safety Guard and Warnings 1. Installation and servicing should be done only by qualified service personnel. 2.Unless the unit is specially marked, it is designed for indoor use only and must not be installed where exposed to rain and moisture. DESCRIPTION Thank you for purchasing our product. -
Page 3: Installation
INSTALLATION Surface Unit Installation In-ceiling Installation... - Page 4 ·Preparation Make three or more holes in the ceiling or wall for the screws that are to be used to secure the main unit. If embedding the input power wire and video out cable, make a hole for these cables to be passed through also.
-
Page 5: How To Operate
HOW TO OPERATE 1. Connect the power Jack (A) (on camera, +12V DC in Jack center) to the DC plug (on AC adaptor). 2. Connect the Video (B) to the monitor or other video device through a 75 Ohms type coaxial cable. Note: AC Adaptor Sold separately. -
Page 6: Specification
SPECIFICATION Image Pick-up Device SONY 1/3” Super HAD CCD Sensor. SONY 1/3” Super HAD CCD Sensor. Effective Picture Elements EIA: 510*492,CCIR: 500*582 (H*V) NTSC:510*492, PAL:500*582 (H*V) Horizontal Resolution 420 TV lines 380 TV lines Minimum Illumination 0.1 LUX @ F2.0 0.4 LUX @ F2.0 S/N Ratio More than 48 Db...
