Summary of Contents for TBK vision RYK416HB
-
Page 1: Instruction Manual
Color DSP CCD Camera Instruction Manual VER.:1.0, NO.:040045A... - Page 2 Thank you very much for purchasing our product. Before operating this product, please read this instruction manual carefully to ensure proper use. 1. Safety Precautious CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE.
- Page 3 3. Features Color camera with a SONY 1/3“ Super HAD CCD sensor. Employed Digital Signal Processor(DSP)chip-set for image control. Pixel Number: NTSC=380K / PAL=440K (High Resolution) NTSC=270K / PAL=320K (Normal Resolution) High Sensitivity, Low Smear, High Anti-Blooming, and a high S/N ratio.
-
Page 4: Name Of Each Parts
4. Name of Each Parts... - Page 5 5. Installation & Operation Please refer to Fig. 1 or Fig. 2 (P3) and setup guide below: 1. Remove the cap cover from the top of the lens mount. 2. Screw the lens into the lens mount. 3. Connect the video output (9) to the monitor or other video device through a 75 Ohms type coaxial cable.
- Page 6 • If the auto iris lens is setup to the DC Drive (or Direct Drive), the Switch (5) should be in position with the DC Drive. Adjust the VR (3) to the proper level. • If video drive iris lens is used, the switch (5) should be in position with the Video DR.
-
Page 7: Auto Iris Control
6. Auto Iris Control DC DRIVER VIDEO DRIVER (Direct DRIVE) VDC OUT DAMP- IRIS OUT DAMP+ N.C. DRIVE+ DRIVE- Auto Iris Lens Connector 7. Packing 1 Camera 1 Allen Wrench 1 4-Pin Connector for Auto Iris Lens 1 Instruction Manual... -
Page 8: Specification
8. Specification 1/3” Color Sony 1/3” Color Sony 1/3” Color Sony 1/3” Color Sony Hi-Res. Super Hi-Res. Ex-View Image Device Super HAD Ex-View Super HAD Super HAD NTSC：510×482, NTSC：768×494, Picture Elements PAL：500×582 PAL：752×582 Resolution 380 TVL 470 TVL Min. Illumination 0.1 Lux/ F1.2 0.05 Lux/ F1.2 0.2 Lux/ F1.2...
