Features and Design This Projector is designed with the most advanced technology for durability and ease of use. This projector utilizes built-in multimedia features, a palette of 1.07 billion colors and matrix liquid crystal display (LCD) technology. Simple Computer System Setting Security Function The projector has the Multi-scan system to The Security function helps you to ensure secu-...
Table of contents Features and Design ......Setting Table of contents Setting............43 ........3 Safety operation guideline Expand .....4 Compliance Language ...........45 ..........11 Accessories Auto Setup ..........45 ..........12 Keystone ............46 Overview Curved correction ........47 Name and function of your projector Logo ............48 Front/top ............14 Security ............49...
Safety operation guideline Safety instructions This document and your projector employ certain symbols to illustrate how to use your projector safely. They are described below: Please get yourself familiar with them before going through this document. Ignoring messages indicated by this symbol may lead to personal injuries Caution or deaths due to human errors.
Page 5
Safety operation guideline Notes Caution Safety precautions: ● GROUND your projector. ● Lens of your projector projects strong light. DO NOT look at the light beam directly. You may get your eyesight hurt. This is especially the case with children. ●...
Page 6
Safety operation guideline Note: Precautions on location of your projector: ● Place your projector in a proper location or it may result in fire. ● DO NOT expose your projector in rain or high humidity environments or it may result in fire or electric shock.
Page 7
Safety operation guideline Note: Precautions on using your projector: ● DO NOT project the same image for long time as residual images may be left in the panel. This is a property of LCD panel. ● Use power as indicated in tags attached to your projector. If you have doubts over available power type, consult your dealer or local power company first.
Page 8
Safety operation guideline Air ventilation Openings in the casing are designed for ventilation and overheating prevention. DO NOT block or cover these openings to keep your projector in normal operation and from overheating. Note: Heat exhaust at the air outlet Keep the following in mind when using or installing your projector: –...
Page 9
Safety operation guideline Place your projector correctly Use your projector at specified location in correct way. Invalid projector location may shorten life-cycle of lamps or even lead to severe incidents or fire. Note: • Enable the “Ceiling” function if flip over screen is required. DO NOT install your projector in ways as illustrated below.
Page 10
Safety operation guideline Moving your projector When moving your projector close its adjustment legs as they may damage the lens and casing. Keep your projector in suitable box when it is not to be used for a long time. Note: Precautions on moving or shipping your projector: ●...
Accessories Remote Control with batteries Quick Start Guide AC Power Cord (AA or LR6) US Type x1 Euro Type x1 Lens Cover Safety Information VGA Cable (For EK-510U, 511W and 512X)
Name and function of your projector Front/top Projection lens Air intake with filter POWER indicator (Refer to Page 77) – The power indicator turns steady red when your projector is in standby mode – It turns steady green when your projector is in normal operation STATUS indicator (Refer to Page 77) It flashes orange when internal temperature of your projector is out of operation range FILTER indicator (Refer to Page 77)
Name and function of your projector Rear DVI-D P/PR B/PB H/HV MONITOR OUT VIDEO S-VIDEO AUDIO AUDIO AUDIO RS-232C AUDIO VOL- VOL+ 360.2 ON/STAND-BY LENS SHIFT Power on or off your projector Enter the lens moving mode / Vol- ENTER / Vol+ –...
– Connect component signals to Y, Pb, Pr termi- is used. nal respectively. HDBaseT (for EK-510U, 510UL, 501W, 501WL) HDMI When the projector is equipped with HD-Ba- Connect HDMI digital output signals or MHL seT function, connect to this terminal through a digital output signals to this terminal.
Name and function of your projector Remote controller HDBaseT Select HDBaseT input source ② ① *This function is not available for EK-512X, 512XL PATTERN Select built-in test pattern of your projector ⑥ ⑦ ③ Select VGA input source ④ ⑧ ⑤...
Name and function of your projector TIMER ② ① Enable the timer function LENS SHIFT ⑥ Enter the lens moving mode ⑦ ③ FREEZE ④ ⑧ Freeze projected images ⑤ ⑨ KEYSTONE ⑩ ⑪ Keystone calibration ⑯ ⑫ INFO. Display current status information of your pro- ⑬...
Name and function of your projector Install battery of remote controller Open the battery cover. Insert a new battery in it. Two AA (LR6) batteries Place your batteries with its anode and cathode (+ and -) in correct direction. Keep both poles in good connection to the contacts within the compartment.
Installation Lens installation Please follow steps given below to install lens after its replacement or when optional ones are employed. Please consult your dealers for details on optional lenses. Lens release button Decoration ring Remove the lens Installing lens 1 Center the lens with its movement func- 1 Align the red mark on your lens and your tion.
Installation Lens shift adjustment The electric lens shift function may adjust your lens in all four directions. This function enables easy image position adjustment. The projection location of your image may be moved upward a distance up to 70% (WXGA) Move lens to it top / 60% (WUXGA / XGA) of the length of the position...
● Values shown in figure below are approximates only. They may differ from the actual ones. 300" 200" 150" 100" 40" EK-510U / EK-510UL, EK-511W / EK-511WL (16:10) Unit:cm Lens Model No. AH-E22010 AH-E22020 AH-E21010 AH-E23010...
Installation Connect the AC power cord Standard voltage employed by your projector is AC 100-240V. It adapts to different input voltage automatically. Your projector employs 2-phase power cord with neutral ground cable. Do not use any other type of power cords or you may face the risks of electric shock.
Connection to equipment Connection to audio equipment Cables for connection: Audio cable* ● (* This cable is optional.) Ports on your projector Connection cable Equipment AUDIO MONO L/R Audio cable AUDIO IN 1 / IN 2 / Audio cable RC IN/ Audio cable RC OUT Connection to USB equipment...
Basic operation Power on your projector DVI-D Power P/PR B/PB H/HV MONITOR OUT VIDEO S-VIDEO AUDIO AUDIO AUDIO RS-232C AUDIO VOL- VOL+ Power 360.2 1. Connect all external equipment to your projector (e.g. computer or camera) before powering it 2. Connect AC power cord of your projector to an AC power socket. The Power indicator turns on in red.
Basic operation Power off your projector Power P/PR B/PB 1. Press the Power button at the rear control MONITOR OUT panel or the remote controller, the “Power VIDEO S-VIDEO AUDIO AUDIO AUDIO RS-232C VOL- VOL+ off?” message displays. 2. Press the Power button again in 4 seconds after the “Power off?”...
Basic operation DVI-D P/PR B/PB H/HV Auto setup MONITOR OUT VIDEO S-VIDEO AUDIO AUDIO AUDIO RS-232C AUDIO VOL- VOL+ ZOOM/FOCUS FOCUS ZOOM LENS SHIFT LENS SHIFT 360.2 Zoom / focus function Zoom / focus 1. Press the ZOOM / FOCUS button on the rear control panel or remote controller for zooming and focusing.
Adjust the projected image when the projector linearity H/V Keystone is uneven or the projected images bent vertically and horizontally. Corner correction (*This function is unavailable of EK-510U/EK-510UL) Reset value Reset value The correction values will be restored to the factory defaults.
Basic operation How to use the OSD Main menu Sub menu Display Auto PC adj. Fine sync H Position V Position H. Size Aspect Normal Project way Front Menu position Center Background display Blue System 1024 x 768, 60Hz Menu operation 1.
Basic operation Menu item overview Main menu Sub menu Display ① Auto PC adj. Fine sync ② H Position V Position ③ H. Size Aspect Normal ④ Project way Front Menu position Center ⑤ Background display Blue System 1024 x 768, 60Hz ⑥...
Basic operation Remote controller operation Use your remote controller for common operations. Screen size selection (SCREEN) Press the SCREEN button on remote controller to select required screen size mode. Digital Zoom (D.ZOOM+/-) Press the D.ZOOM+/- button on remote con- troller to enter the Digital Zoom mode. *Only for input as VGA, RGBHV, and the screen size setting as Normal or Wide.
Input selection Input select Remote control Direct Operation Press HDMI, VGA, VIDEO, HDBase T, COMPONENT, RGBHV or S-VIDEO on the remote control as input source. COMPONENT HDMI VIDEO Menu operation RGBHV HDBase T 1 Press INPUT button on the remote control or S-VIDEO PATTERN control panel to display the input select menu.
Page 36
Input selection Select it when the video input Remote control S-video signal is connected to S-VIDEO IN terminal. When input source is from device Memory Viewer connected to USB-A terminal, please select "Memory Viewer". INPUT When input source is from network Network connected to LAN terminal with LAN cable, please select "Network".
OSD Setting-Display Auto PC Adjusting The Auto PC Adjusting function may get Total Dots, Horizontal and Vertical position, Display area H, and Display area V aligned with computer input. Direct Operation Press Auto button on the remote control to launch the Auto PC Adj. function. AUTO Display menu Menu Operation...
V Position Wide ..Projects the image at 16:9 aspect ratio. H. Size Full ... To provide an image to fit the screen. Aspect Normal (*This function is unavailable of EK-510U/EK- Project way Front 510UL) Advanced Splicing screen. Menu position...
Page 39
V Position H. Size Aspect Normal Project way Front Menu position Center Background display Blue System 1024 x 768, 60Hz Note: Edge blending software and its manual can be downloaded from EIKI website. See page.68 for usage of Edge blending.
Page 40
OSD setting-Display System The projector automatically tunes to various types of computers with its function of Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, the projector automatically de- tects the signal format and tunes to project proper images without any additional setting. One of the following messages may appear when input source as computer: When the projector cannot recognize the connected signal conforming to the Auto...
OSD setting-Color Adjust(Computer signals) Color Adjust Menu operation 1 Press the MENU button on remote controller and the OSD displays. Press button select Color Adjust icon, press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. Image mode Switch image mode to fit the image source and the projector.
OSD setting-Color Adjust(Video signals) Color Adjust Menu operation 1 Press the MENU button on remote controller and the OSD displays. Press button select Color Adjust icon , press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. Image mode Switch image mode to fit the image source and the Color adjust...
OSD setting-Setting Setting Your projector comes with convenient adjustment function. 1 Press the MENU button on remote controller and the OSD displays. Press button to select Setting icon, press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. On start Setting Setting the projector to be turned on automatically...
Page 44
OSD setting-Setting enable this function and change the channel. Press to select Off, CC1, CC2, CC3 or CC4. Setting On start Keylock Standby mode Set the security for the projector operation. High land Lamp control O ff ......Cooling fast Normal Closed caption The control panel and remote controller are...
OSD setting-Expand Expand Select the Expend menu to set up other functions of your projector. 1. Press the MENU button on remote controller and the OSD displays. Press button to select Expand icon, press button or OK button to enter the submenu. 2.
OSD setting-Expand Keystone Keystone menu This function is used to store or reset the keystone correction when the AC power cord is Expend unplugged. Keystone 1 Press MENU button on the remote control to Keystone Store display screen menu. Press button to select H/V Keystone "Expand", then press the OK button.
OSD setting-Expand Curved correction (For XGA and WXGA model only) Adjust when the linearity is not uniform or the vertical and horizontal lines are distorted. Press▲▼◄►to adjust the item. Items Operation Adjustment Press the◄ & ► Adjust the right & left of the button width Curved...
OSD setting-Expand Logo This function allows you to customize the screen logo with Logo select, Capture, Logo PIN code lock and Logo PIN code change functions. Logo Select This function decides on the starting-up display Logo from following options. Default . Show the factory-set logo. Expend User ..
OSD setting-Expand Security Security This function allows you to use the PIN code lock and PIN code change functions to set the Expend security for the projector operation. Language Auto setup Keystone PIN code lock Logo This function prevents the projector from Security being operated by unauthorized persons Power management...
OSD setting-Expand Power management Power management For reducing power consumption as well as Expend maintaining the lamp life, the Power management Language function turns off the projection lamp when the Auto setup projector is not operated for a certain period. Select Keystone one of the following options: Logo...
OSD setting-Expand Test Pattern This function is used to set the internal test Test Pattern signal: Gray scale 1, Gray scale 2, Gray scale 3, Gray scale 4, Color bar, Red, Green, Blue, Expend Cross hatch, White, Black and Raster gray. Language Auto setup Keystone...
OSD setting-Expand (3) When DHCP is set On, IP address, Subnet, Network setting Gateway and DNS will be obtained DHCP automatically, press the OK at "Set" to confirm IP address Subnet the parameters. Gateway When DHCP is set Off, press the OK button to Cancel enter IP address, then press ...
OSD setting-Memory Viewer Memory Viewer The Memory Viewer function makes it possible to project the pictures which are stored in the USB memory when the USB memory is inserted into the projector 1 Press MENU button on the remote control to display screen menu. 2 Press ...
OSD setting-Info. Information The information menu is used to the detect signal of projected image and running state. Menu operation info. menu Press MENU button on the remote control or control panel to display the screen menu. Press to select Info., the information menu Info.
Description on network control operation LAN control Function : PC controls projector via LAN. Preparation: 1. Equipments: PC, projector, cables 2. Connection procedures: Connect the projector to routers or switches of the LAN by direct or cross cable. If it fails to connect PC and projector by parallel cable, please switch to cross cable as suggested.
Page 57
Description on network control operation 4. Activate the Web browser in the personal computer. 5. Enter the IP address set by the projector into the URL input field of the Web browser. 6. Select "Login" to login the Network Display System page. (Both the initial name and passwords are "admin".) ...
Page 58
Description on network control operation "System Status" page Display the status of the projector for the following items. ① ② ③ ① Model Name ③ LAN Status Displays the model No. of the projector. Displays the connection status of the LAN. ②...
Page 59
Description on network control operation ① Brightness ④ Color Adjusts the brightness of the projected image. Adjusts the color saturation of the projected image. ② Contrast Adjusts the contrast of the projected image. ⑤ Tint Adjusts the skin tone of the projected image. ③...
Page 60
Description on network control operation "Network Setup" page ① ② ① LAN Setup Gateway Select [Obtain an IP address automatically] Enter the default gateway address when if you want to enable the DHCP client. not using a DHCP server. IP Address Enter the IP address when not using a DHCP Enter the DNS server when not using a server.
Page 61
Description on network display operation Network Display function 1. PwPresenter software: when "Network" is selected in Source Select, you can project the current computer images via network. Input the IP address of the projector in webpage to enter the Network Display System, click "Download"...
Page 62
Description on network display operation Play/Pause ② Play or pause the selected image. ③ Choose capture mode Choose a capture mode from "Full Screen", "Fixed Size" or "Alterable." ④ Parameters Setting Basic Setting Setting language, region of capture image etc. Advanced Setting Setting image quality, network port etc.
Page 63
Description on network display operation Multicast Setting Setting Sound volume, Bandwidth and Capture rate etc. ⑤ Network Display Management Setting device and password management. ⑥ Disconnect the projector.
Description on using Memory Viewer function Memory Viewer function The Memory Viewer function is used to project the pictures which are stored in the USB memory when the USB memory is inserted into USB A(VIEWER) terminal of the projector. Memory Viewer function supports the following image files. Extension Format Description...
Page 65
Description on using Memory Viewer function Play the PDF Playing the PDF file. press ▲▼◄► to select a PDF file and press the OK button, playing the PDF on the full screen. Displays the previous or next page. The page number increases or decreases by 5 pages. The page number increases or decreases by 1 page.
Description on using USB display function USB Display function The USB Display function is used to project the image from the computer which is connected to Micro- USB(DISPLAY) terminal of the projector by a USB converting cable. ■ When using Windows Windows operation environment Windows Vista 32 bit, Windows 7 32/64 bit, Windows 8 32/64 bit Intel Core 2 Duo 2.0 GHz or faster, the compatible processor...
Page 67
Description on using USB display function ■ When using Mac OS Mac OS operating environment Mac OS X 10.5, 10.6, 10.7 Power PC G4 1GHz or faster Amount of memory 512 MB or more Hard-disk free space 20 MB or more Display Resolution 640 x 480 or more, 1 600 x 1 200 or less ●...
Adjustment: The color and effect of the overlay edge can be adjusted with the Edge Blending software. The Edge Blending Software and its manual can be downloaded from EIKI website. URL: http://www.eiki.com Note: ● Edge Blending function can only effected with the same resolution projectors.
Regular maintenance Status light indicator The status light indicator shows status of projector protection function. Check status and POWER light indicator for good maintenance operation. Note: Unplug the AC power cord in case of any abnormality as it may lead to fire or electric shock.
Regular maintenance Clean your projector when it is contaminated by foreign matter or its display effects are getting worse. Note: Unplug the AC power cord before any cleaning operation. Clean the lens Wipe the lens with clean cloth dampened with non-abrasive camera lens cleaner or clean it with lens cleaning paper or air blower.
Regular maintenance Reset the filter counter 1 Press MENU button and the OSD displays. Press button to select Expend menu, press button or OK. 2 Press button to select "Filter Counter", press button or OK. Press button to select “Filter counter reset” and press OK. The “Filter counter reset?” message dis- plays.
Page 73
Regular maintenance Follow steps below to replace the lamp: Screw 1. Power off your projector and unplug the AC 螺钉 power cord. Let it cool down for at least 45 minutes. 2. Open the lamp cover after removing screws holding the cover. 3.
Appendix Troubleshooting Check the following before calling your dealer or service center: Troubleshooting Solution Power on failure – Plug the power cord of your projector in an AC socket. – Make sure the POWER light indicator turns red. – Restart your projector until the POWER light indicator turns red. It indicates your projector is ready for power on again.
Page 76
Appendix No image displays – Check for the connection between your projector and computer or image equipment. – Check for correct input signal from computer. Connection with certain notebook computer may mandate changes to its display output settings. See the user manual included with the computer for details on settings.
Page 77
Appendix Exclamation mark – Invalid operation, please operate your projector correctly. displays Control panel does not – Disable the key lock on control panel function in the Safety option function of the Setup menu. Cannot remove the Logo – Please call your dealer or service center. Select password, Key Lock, and PIN Code lock –...
Appendix Light indicator status Check light indicator to learn status of your projector. Light indicator Status of your projector STATUS FILTER POWER Green /Red Your projector is in Off status (without AC power supply). Your projector is in standby status. Press Standby button to turn it Your projector is in normal status.
Appendix Compatible computer screen Your projector is designed to accept every analog computer signal below Dot Clock 160MHz and digital computer signal below Dot Clock 150MHz. See table below for details on resolution and relevant frequency. Signal Frequency Signal Frequency Input Resolution Input...
-5 - +5 The range of H Size H Size -15 - +15 differs from signals. Normal *This function is Wide Aspect Normal disable on EK-510U/ Advanced EK-510UL Full* Front Rear Ceiling / Front Project way Front Ceiling / Rear...
Page 82
Keystone Store / Reset Store H/V Keystone Expand Corner correction Keystone (This function is disable Curved correction on EK-510U Reset value Logo select Default/User/Off (This function is disable Capture on EK-510U) Logo Logo PIN Code Lock On/Off Logo PIN Code Change...
Page 83
Appendix Main menu Sub-menu Setting Default value Remarks PIN code lock On/Off Security PIN code change Ready Shut down Power Ready management Timer Ready Countdown Filter counter Filter counter Timer Timer Filter counter reset Off,Gray scale(1-4) ,Color Test pattern bar, Red, Green, Blue,Cross Expand hatch ,White,...
Page 84
Appendix Main menu Sub-menu Setting Remarks Input H- sync. Freq. V- sync. Freq. Info. Lamp status Lamp counter Power management Image mode Input RGBHV HDMI1 HDMI 2(MHL) HD-BaseT Component Video S-video Memory Viewer Network USB display...
Page 86
Appendix Type Short Lens Short Zoom Lens Standard Lens Long Zoom Lens Long Zoom Lens Model Number AH-E22010 AH-E22020 AH-E21010 AH-E23010 AH-E23020 Zoom Fixed x1.3 Power zoom x1.8 Power zoom x1.6 Power zoom x1.7 Power zoom Iris (F) 2.0 - 2.6 1.8 - 2.6 2.2 - 2.8 2.2 - 2.8...
Appendix PIN code memorandum Write down the PIN code in the blank below and keep it, If you forgot or lost the number and unable to operate the projector, contact the service center. Factory default PIN code 111* PIN code lock Factory default PIN code 111* Logo PIN code Lock No.
Page 89
+420 241-403-095 Fax: +420 241-409-435 E-Mail: info@eiki.cz China South East Asia EIKI (Shanghai) Co., Ltd. EIKI Industrial (M) Sdn Bhd LAKESIDE OASIS MIDDLE RING No. 11, Nouvelle Industrial Park, BUSINESS CENTRE Lorong Teknologi B, Taman Sains Block 1,Room 606, Selangor 1, Kota Damansara PJU5,...
