- Page 1 ● Push-buttons and LEDs DEIF A/S · Frisenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45 9614 9615 · info@deif.com · www.deif.com isenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45 9614 9615 · info@deif.com · www.deif.com Document no.: 4189340849A...
-
Page 2: Table Of Contents
CGC 400 quick start guide 4189340849 UK 1. General information 1.1. Warnings, legal information and safety....................3 1.1.1. Warnings and notes ........................3 1.1.2. Legal information and disclaimer ....................3 1.1.3. Safety issues ..........................3 1.1.4. Electrostatic discharge awareness ....................3 1.1.5. Factory settings ..........................3 1.2. -
Page 3: General Information
1.1.2 Legal information and disclaimer DEIF takes no responsibility for installation or operation of the generator set. If there is any doubt about how to install or operate the engine/generator controlled by the unit, the company responsible for the installation or the operation of the set must be contacted. -
Page 4: About The Quick Start Guide
CGC 400 quick start guide 4189340849 UK General information 1.2 About the Quick Start Guide 1.2.1 General purpose This Quick Start Guide mainly includes general product information and descriptions of terminals, push-button functions and LED functions. The general purpose of this document is to help the user with the first steps of installing and using the CGC 400. -
Page 5: What's In The Delivery
CGC 400 quick start guide 4189340849 UK What's in the delivery? 2. What's in the delivery? 2.1 Standard delivery The main unit ● 6 mounting clamps ● Terminal connectors 2.2 Optional delivery PC cable for utility software (option J7) DEIF A/S... -
Page 6: The First Steps
CGC 400 quick start guide 4189340849 UK The first steps 3. The first steps 3.1 Switching on the first time 3.1.1 Terminals The dashed lines in the diagram below show the most important terminals to use in order to get started. Once all connections to the unit are made, the unit is ready to be switched on. -
Page 7: Connection
3.2.2 Connection Connect the CGC 400 port to a USB port on the computer using a standard USB type A to type B (option J7). Open the utility software on the computer and enter the “Application settings” (F3). Choose the COM port named as shown below. -
Page 8: Display Push-Buttons And Leds
CGC 400 quick start guide 4189340849 UK Display push-buttons and LEDs 4. Display push-buttons and LEDs 4.1 Push-button functions The push-buttons on the unit have the following functions: Function Secondary functionality Scroll the display up once Programming: Increase setpoint value... -
Page 9: Led Functions
The display unit holds 10 LED functions. Dependent on the situation, the colour of the LEDs is green, red or a combination. The table below describes the functionality of the LEDs on the CGC 400: LED no. LED name LED function... -
Page 10: Display Structure
Not used Output B: Not used For further information, please refer to the following documents: CGC 400 Designer's Reference Handbook, document no. 4189340786. CGC 400 Installation Instructions, document no. 4189340785. CGC 400 Operator's Manual, document no. 4189340787. DEIF A/S Page 10 of 10...
