Master Chef 85-3129-6 Propane Assembly Manual page 10

AssEMBLY instRUCtions
8
ec
A
Front, left side view
B
Back view
B2
c
View, under left side shelf
BA
d
View, under left side shelf
BA
ed
BA
A1
A1
ec
B2
BA
left side sHelf AsseMBlY
a. Insert the Left Side Shelf Assembly (EC and ED)
into the support brackets located on the right
side of the Burner Box Assembly (BA).
b. Affix the Left Side Shelf Table (EC) to the Burner
Box Assembly (BA) as shown in figures B and C.
ec
yOU WILL NEED:
1
X 4
yOU WILL NEED:
B2
ed
2
X 4
c. Affix the Left Side Shelf Fascia (ED) to the
Control Panel (CA).
securely tighten all hardware.
yOU WILL NEED:
ed
3
cA
X 3
8
A1
4
X 4
