[MAS 001] G30101 BBQ Manual E
SERIAL #:
Propane Barbecue
3 - Y E A R L I M I T E D W A R R A N T Y
8 5 - 1 2 6 1 - 0 ( P R O P A N E )
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
For product inquiries, parts, warranty
and troubleshooting support, please call
1-877-707-5463
8/31/05
2:06 PM
Page i
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
( G 3 0 1 0 1 )
F O R Y O U R S A F E T Y
If You Smell Gas
1. Immediately turn off the flow
of gas to the unit.
2. Extinguish any open flame.
3. Open the lid of the unit.
4. If the odour does not stop quickly,
immediately call your gas supplier
or Fire Department for assistance.
F O R Y O U R S A F E T Y
1. Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or other appliance.
2. An LP Gas cylinder not connected for
use shall not be stored in the vicinity
of this or other appliance.
W A R N I N G
Failure to follow all of the manufacturer's
instructions could result in hazardous
fires, explosions, property damage,
or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully prior
to operation of barbecue, even if barbecue
was stored assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this man ual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
