Master Chef 85-3129-6 Propane Assembly Manual page 7

AssEMBLY instRUCtions
3
dH
dG
A
B
Close up
4
dJ
Back View
df
5
5
6
c
Close up
dd
de
dc
dJ
Close up - front view
dJ
Close up - back view
note: turn Cart assembly upside down.
a. Place Wheel (DG) and Wheel Spacer (#5) onto
the Wheel Axle (DH). "Cone" side of wheel
6
5
should be against cart side panel. Figure B.
b. Insert Wheel Axle Assembly (DH) through
7
wheel axle hole in the front and rear of the Left
dG
Cart Side Panel (DB), as shown.
c. To complete wheel assembly position the
dB
Wheel Spacer (#5), Wheel (DG), Wheel Washer
(#6) and Hitch Pin (#7), onto Wheel Axle (DH)
as shown.
d. Insert End Caps (DF) into Right Cart Side Panel
(DA).
yOU WILL NEED:
7
6
5
X 2
Assemble the three Tank Exclusion Wires (DJ) to
the Lower Back Brace (DC) and the Front Panel
(DD and DE) as shown.
yOU WILL NEED:
10
X 3
5
7 6 8 7
X 1 X 1
11
X 3
