Master Chef 85-3129-6 Propane Assembly Manual page 8

AssEMBLY instRUCtions
5
Back View
6
+
A B
c
A
B
dB
dB
Close up
dB
dA
ProPAne Model onlY.
Assemble the Gas Tank Support (DK) to Left Cart
Side Panel (DB).
dK
dK
note: tWo PEoPLE required for this step.
Ensure that the regulator hose (CE) (Propane
models only) is hanging outside of cart.
a. Position the Lid and Burner Box Assembly
(A & B), onto the cart assembly (C).
b. Assemble the Burner Box Assembly (BA) to the
BA
cart assembly (C) as shown in figure B.
yOU WILL NEED:
1
X 4
6
