2.4.3h Reynolds Correction
12. Scroll to the appropriate choice to indicate whether you want Reynolds Correction.
•
If Off is selected, enter the Calibration Factor and press
•
If Activ is selected, the program asks for KV Input Selection. Scroll to SIGS (Signals), SOUND
(Soundspeed) or STATC.
•
If SIGS or SOUND is selected, enter the Calibration Factor and press
•
If STATC is selected, enter the Kinematic Viscosity and press
Factor and press
•
For wetted transducers, the program returns to the
parameters.
PIPE
•
For clamp-on transducers, proceed to step 13 below.
Number of Traverses
13. Scroll to the appropriate Number of Traverses (from 1 to 5) and press
14. Accept the value for the Transducer Spacing by pressing
Note: The XMT868i automatically calculates the transducer spacing. You should not enter a different value unless
specifically instructed by the factory.
The User Program returns to the
Note: The site data programmed in this chapter is automatically stored in the meter's non-volatile RAM (NVR). If the
power to the meter is disconnected, the same site data will be applied when the unit is next powered On.
2.4.3i Procedure Options
Proceed to Chapter 3, Operation, for instructions on taking measurements. Or refer to the Programming Manual for
instructions on programming the Model XMT868i's advanced features.
DigitalFlow™ XMT868i Startup Guide
.
[Enter]
menu. You have completed entering
Channel PROGRAM
.
[Enter]
[Enter]
menu. You have completed entering
Channel PROGRAM
[Enter]
. Record the value.
[Enter]
Chapter 2. Initial Setup
.
[Enter]
. Then enter the Calibration
.
parameters.
PIPE
43
