ARIB content displays
212
The decoded ancillary data includes the following:
■ DID - Data Identifier of the requested closed captioning packet; can be any of
the following:
■ Analog signal - 0x5F
■ SD Signal - 0x5
■ HD Signal - 0x5F
■ SDID - Secondary Data Identifier of the requested packet; can be any of the
following:
■ Analog signal - 0xDD
■ SD Signal - 0xDE
■ HD Signal - 0xDF
■ Mobile signal - 0xDC
■ Field/Line - The field or line of the video from which the packet was
acquired. Displays 1 for progressive formats.
NOTE. The Line field turns red if the ARIB B.37 packets are not on the line as
defined by ARIB TR-B.23.
■ Format - Indicates the name of the ancillary data type or standard.
■ Header 1st - Displays the first of four User Data Words of the corresponding
packet, in binary.
■ Header 2nd - Displays the second of four User Data Words of the
corresponding packet, in binary.
■ Header 3rd - Displays the third of four User Data Words of the corresponding
packet, in binary.
■ Header 4th - Displays the last of four User Data Words of the corresponding
packet, in binary.
■ ECC Status - Indicates the presence or absence of the Error Correcting Code
information in the payload.
■ Format ID - Indicates whether the packet is for HD, SD, Analog, or Mobile
captions.
■ Language - Indicates the language code (1st through 8th) of the packet.
■ CC Data ID - Indicates the CC Data ID of the packet. Can be one of the
following:
■ Exchange Format CC
■ Exchange Format PMI
■ Exchange Format Page 1
■ Exchange Format Page 2
■ Short Form Management Data
