Battery Charging

The transmitter operates from a 3.7 V rechargeable
battery that will provide about six hours of operation
per charge. Battery life can be monitored from the timer
function built into current Lectrosonics receivers.
The factory supplied battery charger provides a folding
NEMA 2-prong plug, and will operate from 100-240 VAC
sources. The LED glows red during charging and turns
green when the battery is fully charged.
Battery charger
Lectrosonics part number 40100
CAUTION: Use only the factory supplied
battery and battery charger.
Rio Rancho, NM
Micro Body Pack Transmitter

Battery Installation

The battery compartment and door catch are designed
for simple and quick battery changes, yet prevent the
door from being opened accidentally.
Squeeze tabs inward
to release door catch
Battery contacts
Insert battery
contact end first
Press opposite end of
battery into compartment
If the battery is inserted incorrectly, the door will close
but the unit will not operate.
