SSM
Digital Hybrid Wireless
SSM, SSM-941, SSM/E01, SSM/E01-B2, SSM/E02, SSM/E06, SSM/X
Quick Start Steps
1)
Install a good battery and turn power on (see pages
5 and 8).
2)
Set the compatibility mode to match the receiver
(see page 9).
3)
Connect the signal source and adjust input gain for
optimum modulation level (see page 10).
Set Step Size and frequency to match receiver (see
4)
pages 8 and 9). Also refer to the receiver manual for
the RF scanning procedure to find a clear operating
frequency.
5)
Turn on the receiver and verify that solid RF and
audio signals are present (see receiver manual).
WARNING: Moisture, including talent's sweat,
will damage the transmitter. Wrap the SSM
in a plastic bag or other protection or use the
SSMCVR to avoid damage.
Fill in for your records:
Serial Number:
Purchase Date:
Micro Transmitter
®
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lectrosonics Digital Hybrid Wireless SSM
Summary of Contents for Lectrosonics Digital Hybrid Wireless SSM
-
Page 1: Quick Start Steps
WARNING: Moisture, including talent’s sweat, will damage the transmitter. Wrap the SSM in a plastic bag or other protection or use the SSMCVR to avoid damage. Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com... - Page 2 SSM, SSM-941, SSM/E01, SSM/E02, SSM/E06, SSM/X LECTROSONICS, INC.
-
Page 3: Table Of Contents
Micro Body Pack Transmitter Table of Contents Quick Start Steps ....................................1 About Digital Hybrid Wireless ................................4 ® Battery Charging ....................................5 Battery Installation ....................................5 Controls and Functions ..................................6 Modulation LEDs ....................................6 LCD Screen ......................................6 BATT LED ......................................6 AUDIO Button ......................................6 FREQ Button ......................................6 Power Button .......................................6 UP and DOWN Arrow Buttons................................6 Turning LEDs ON and OFF ..................................6... -
Page 4: About Digital Hybrid Wireless
Four tuning ranges are available covering standard range and resistance to interference. blocks as follows: The Lectrosonics Digital Hybrid Wireless system over- Range Blocks Covered Freq. MHz comes channel noise in a dramatically new way, digitally 470, 19, 20 470.1 - 537.5... -
Page 5: Battery Charging
Battery life can be monitored from the timer func- tion built into current Lectrosonics receivers. Squeeze tabs inward to release door catch The factory supplied battery charger kit* provides a fold- ing NEMA 2-prong plug on the charger, and will operate from 100-240 VAC sources. -
Page 6: Controls And Functions
DSP controlled limiter to hexadecimal number that corresponds to the equivalent prevent distortion at high input levels. Lectrosonics Frequency Switch Setting. It is important to set the gain (audio level) high enough Power Button to achieve full modulation during louder peaks in the audio. -
Page 7: Connectors And Usb Port
Micro Body Pack Transmitter Connectors and USB Port Attaching and Removing The housing is machined out of a solid aluminum billet the Microphone for a rugged, lightweight assembly. Align the ridges on the plug with the grooves in the jack IR (infrared) port and insert the plug. -
Page 8: Operating Instructions
UP or DOWN arrow button while powering the transmitter. unit on. See the following page (Setup Screens) for a listing of the menu items and descriptions. Call the factory if you have questions about this issue LECTROSONICS, INC. -
Page 9: Setup Steps
NOTE: Full modulation is achieved at 0 dB, when the “-20” LED first turns red. The limiter NOTE: Some Lectrosonics receivers include an can cleanly handle peaks up to 30 dB above this IR (infrared) port to transfer settings from the point. -
Page 10: Setup Screens
In dYn bIAS 0, rES 0; use for dynamic microphones; positive polarity In 152 bIAS 4, rES 0; same as otH; listed for easy selection on Lectrosonics 152 and similiar mics; positive polarity In SEn bIAS 4, rES 0; same as otH; listed for easy selection on Sennheiser MKE 2 and similiar mics;... -
Page 11: Microphone Wiring
Micro Body Pack Transmitter Old Configuration: Microphone Wiring Pin 1: Shield (ground) Looking into the 3 pin Lemo mic connector from the out- Pin 3: Audio and bias side of the transmitter, the pin centered in the two guide NOTE: This line input configuration is found on slots is pin 1 (ground). -
Page 12: Ir (Infrared) Sync
LCD stating what the problem is. Removable Belt Clip The belt clip may be removed by sliding it off the retain- ing tabs on the battery door. Retaining tabs When mounting the belt clip onto the battery door, care- LECTROSONICS, INC. -
Page 13: Lectrorm
• The remote control function must be enabled on to prevent accidental activation of the tone. the transmitter. Please be aware this app is not a Lectrosonics product. It is privately owned and operated by New Endian LLC, www.newendian.com. The iPhone version keeps each available setting on a separate page with the list of options for that setting. -
Page 14: Accessories
MCATA5MLEMO Mic cable adapter; Converts standard TA5F microphones USB Battery charger kit to LEMO connector for use with SSM Transmitter. P/N 40117 charger for Lectrosonics LB-50 battery; includes charger, EU plug adapter and vehicle auxiliary power cord. Port Cover P/N P1311 Micro USB port cover... -
Page 15: Firmware Update
Updater is not installed on your system. Follow the TROUBLESHOOTING steps to fix the error. transmitter connected to a computer via the USB port. Go to www.lectrosonics.com/US. In the top menu, hover the mouse over Support, and click on Wireless Support. On the right-hand-side Wireless Support Menu, choose Wireless Downloads. - Page 16 Step 7: Refer to Step 1 to return to Firmware web page. Down- In Lectrosonics USB Firmware Updater, choose the load Firmware Update and save to a local file on your PC detected device, browse to local Firmware File and click for easy locating when updating.
-
Page 17: Specifications
Micro Body Pack Transmitter Specifications Operating Frequencies: Audio Performance (Digital Hybrid and Nu Hybrid) SSM: Band A1: 470.100 - 537.575 Frequency Response: 70 Hz to 20 kHz (+/-1dB) Band B1: 537.600 - 607.950 Low frequency roll-off: –12 dB/octave; 70 Hz SSM/E01: Band A1: 470.100 - 537.575 Band B1: 537.600 - 614.375 THD: 0.2% (typical) -
Page 18: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 19 Micro Body Pack Transmitter Rio Rancho, NM...
- Page 20 SSM, SSM-941, SSM/E01, SSM/E02, SSM/E06, SSM/X LECTROSONICS, INC.
- Page 21 Micro Body Pack Transmitter Rio Rancho, NM...
- Page 22 SSM, SSM-941, SSM/E01, SSM/E02, SSM/E06, SSM/X LECTROSONICS, INC.
- Page 23 Micro Body Pack Transmitter Rio Rancho, NM...
- Page 24 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
