MAKERBOT REPLICATOR+ DIAGRAMS

1

5

6

7

1. Filament Spool Pocket

2

2. Gantry

3. Build Plate

4. Action Button

3

4

5. Power Switch

6. Power Input Port

8

7. USB Port

8. Extruder Assembly
