Default Settings

Here are the default panel settings which appear
when pressing the Preset key.
Output Config.
Modulation
(AM/FM/FSK)
Sweep
68
nd Quality Products Online at:
AFG-3021/3022/3031/3032 User Manual
Function
Frequency
Amplitude
Offset
Output units
Output terminal
Carrier Wave
Modulation waveforms 100Hz Sine wave
AM Depth
FM Deviation
FSK Hop Frequency
FSK Frequency
PWM Duty
PWM Frequency
Modem Status
Start/Stop frequency
Sweep time
Start/Stop amplitude
Sweep function
Sweep status
GlobalTestSupply
www.
Preset
Sine wave
1kHz
3.000 Vpp
0.00V dc
Vpp
50Ω
1kHz Sine wave
100%
100Hz
100Hz
10Hz
50%
20kHz
Off
100Hz/1kHz
1s
1.000/3.000 Vpp
Linear
Off
