GW Instek AFG-3022 User Manual page 334

Example
SOURce[1|2]:BURSt:TRIGger:SLOPe
Description
Syntax
Parameter
Example
Query Syntax
Return Parameter POS
Example
SOURce[1|2]:BURSt:GATE:POLarity
Description
nd Quality Products Online at:
SOUR1:BURS:TRIG:DEL
+1.0000E+01
The trigger delay is 10 seconds.
Sets or queries the trigger edge for externally
triggered bursts from the Trigger INPUT terminal
on the rear panel for the selected channel. By
default the trigger is rising edge (Positive).
SOURce[1|2]:BURSt:TRIGger:SLOPe
{POSitive|NEGative}
POSitive
NEGative
SOUR1:BURS:TRIG:SLOP NEG
Sets the trigger slope to negative.
SOURce[1|2]:BURSt:TRIGger:SLOPe?
NEG
SOUR1:BURS:TRIG:SLOP
NEG
The trigger slope is negative.
In gated mode, for the selected channel, the
function generator will output a waveform
continuously while the external trigger receives
logically true signal from the Trigger INPUT
terminal. Normally a signal is logically true when
it is high. The logical level can be inverted so that a
low signal is considered true.
GlobalTestSupply
www.
REMOTE INTERFACE
Source Specific
Command
rising edge
falling edge
rising edge
falling edge
Source Specific
Command
