GW Instek AFG-3022 User Manual page 303

Query Syntax
Return Parameter SIN
Example
SOURce[1|2]:PM:INTernal:FREQuency
Description
Syntax
Parameter
Example
Query Syntax
Return Parameter <NR3>
Example
SOURce[1|2]:PM:DEViation
Description
304
nd Quality Products Online at:
AFG-3021/3022/3031/3032 User Manual
Sets the PM modulating wave shape to sine.
SOURce[1|2]:PM:INTernal:FUNCtion?
Sine
SQU Square
TRI Triangle
SOUR1:PM:INT:FUNC?
SIN
The shape for the modulating waveform is Sine.
Sets the phase modulation frequency for the
selected channel. The default frequency is 100Hz.
SOURce[1|2]:PM:INTernal:FREQuency
{<frequency>|MINimum|MAXimum}
<frequency>
SOUR1:PM:INT:FREQ +1.0000E+02
Sets the phase modulation frequency to 100Hz.
SOURce[1|2]:PM:INTernal:FREQuency?
[MINimum|MAXimum]
SOUR1:PM:INT:FREQ? MAX
+2.0000E+04
Returns the maximum frequency allowed.
Sets or queries the peak phase deviation of the
modulating waveform from the carrier waveform
for the selected channel. The default peak
deviation is 180.0°.
GlobalTestSupply
www.
UPRAMP Upramp
DNRAMP Dnramp
Source Specific
Command
2mHz~ 20kHz
Returns the frequency in
Hz.
Source Specific
Command
