Selecting Sweep Mode

The Sweep button is used to output a sweep. If no
settings have been configured, the default settings
for output amplitude, offset and frequency are
used.

Sweep Type

Sweep type is used to select between whether a frequency or
amplitude sweep is performed.
Panel Operation 1. Press the Sweep key.
Example
136
nd Quality Products Online at:
AFG-3021/3022/3031/3032 User Manual
2. Press F2 (Type/MOD).
3. Press F1 (Type).
4. To select frequency or
amplitude sweep, press F1
(Frequency) or F2 (Amptd).
Frequency
GlobalTestSupply
www.
Sweep
Sweep
Type/MOD
Type
~
Frequency
F 1
Amplitude
.com
sales@GlobalTestSupply.co
F 2
F 1
Amptd
F 2
