GW Instek AFG-3022 User Manual page 273

SOURce[1|2]:PHASe
Description
Syntax
Example
Query Syntax
Return Parameter <NR3>
Example
SOURce[1|2]:PHASe:ALIGn
Description
Syntax
Example
SOURce[1|2]:DCOffset
Description
Note
274
nd Quality Products Online at:
AFG-3021/3022/3031/3032 User Manual
Sets or queries the output phase angle (-360º~360º)
of the selected channel. The default phase is 0º.
SOURce[1|2]:PHASe{<angle> |MINimum|MAXimum}
SOUR[1]:PHAS:MAX
Sets the output phase to the maximum.
SOURce[1|2]:PHASe {MINimum|MAXimum}
SOUR1:PHAS?
+1.2000E+01
The phase is set to 12º.
Aligns the timebase of both channels but doesn't
change the phase deviation of the channels. In
other words it re-calibrates the phase difference
between both of the channels.
SOURce[1|2]:PHASe:ALIGn
SOUR[1]:PHAS:ALIG
Turns on the phase align function.
Sets or queries the DC offset for the current mode.
The offset parameter can be set to MINimum,
MAXimum or DEFault. The default offset is 0
volts. The offset is limited by the output amplitude
as shown below.
GlobalTestSupply
www.
Source Specific
Command
Returns the phase in
degrees.
Source Specific
Command
Source Specific
Command
