LCD display
Function keys:
F1~F6
Operation keys
Preset
16
nd Quality Products Online at:
AFG-3021/3022/3031/3032 User Manual
TFT color LCD display, 480 x 272 resolution.
Activates the functions which
F 1
appear in the bottom of the LCD
display.
Waveform is used to select a
Waveform
waveform type.
The FREQ/Rate key is used to set
FREQ/Rate
the frequency or sample rate.
AMPL sets the waveform
AMPL
amplitude.
Sets the DC offset.
DC Offset
The UTIL key is used to access the
UTIL
save and recall options, set the
remote interface (USB, GPIB,
LAN), use DSO link (AFG-
3021/3031), update and view the
firmware version, access the
calibration options, output
impedance settings (AFG-
3021/3031 only), set the language
and access the help menu.
ARB is used to set the arbitrary
ARB
waveform parameters.
The MOD, Sweep and Burst keys
MOD
are used to set the modulation,
sweep and burst settings and
Sweep
parameters.
Burst
The preset key is used to recall a
Preset
preset state.
