Eaton 93PM Installation And Operation Manual page 91

93PM IAC-D 150kW
93PM IAC-D 200 kW
A
480V
B
INPUT
3Ø
C
TBG
G
INPUT GROUND
G
INTER-CABINET STRAP
G
GND
A
208Y/120V
B
3Ø
C
NEUTRAL FOR
OPTIONAL SUB-FEED
Figure 5-11. 93PM IAC-D (150 kW and 200 kW, 480V/208V) Schematic – Two PRL1A Panelboards
Eaton 93PM Integrated Accessory Cabinet-Distribution (50–200 kW) Installation and Operation Manual P-164000229—Rev 6
T1 -TRANSFORMER
PRI: 480V DELTA
SEC: 208/120Y WYE
UOB
H1
H2
H3
GND
PMB1
225A
(TOP)
42-pole
PRL1A
Panelboard
G
PMB2
400A
(BOTTOM)
42-pole
PRL1A
Panelboard
G
Panelboard
XOB
Optional Breaker
Terminal
225A
Block
A
B
C
225A 80%
FD-Frame
N N
N N
X1 X2 X3
N
N
TB-N
www.eaton.com/powerquality
Onelines and Schematics
FAN3
FAN2
FAN1
X0
5-7
