HOME AXES
"HOME AXES" moves the extruder to the lower left corner.
To home axes:
home axes
are you sure
NO
YES
Select "YES" to proceed.
JOG MODE
"JOG MODE" is used to manually move the extruder and the print bed.
To move the extruder:
jog mode
x - axis
y - axis
z - axis
1.Select "X-AXIS" (to move right
and left) and "Z-AXIS" (to move up and down).
Execute "Home Axes" function first to move
"Z-AXIS". "Y-AXIS" (to move print bed
backwards and forwards).
BUILD FROM CARD
3 sample models are built into the printer. You may begin your first 3D prints with the samples.
To print a sample:
build FROM CARD
demo
1.Select a sample to print
DEMO
start building
no
yes
3.Select "YES" to start printing
HD23F1JP0E8
2.Select desired increment of travel with
buttons, and press (or hold)
direction to move the extruder.
2.Put the bed tape on the print bed.
4.Remove the printed object when the printing has
finished and the print bed has descended.The bed
tape is reusable and it can be replaced when it's worn.
UTILITIES
da Vinci Jr.1.0 Pro
x-axis ok exit
－ ■ 001mM ＋
010mm
020mm
or
May 2016
and
button for desired
