Operation
Receiver State
OBER Sat 1A
OBER Sat 1B
OBER Sat 2A
OBER Sat 2B
OBER Terr A
OBER Terr B
Turbo Word Error
Rate
(Pipe 0A)
Turbo Word Error
Rate
(Pipe 0B)
Module TypeID A/
VOL
B/C
Up/Down
Module HWRev A/
B/C
ModSWRevMajor/
Minor/Inc
SXIRevMajor/Mi-
nor/Inc
BBRevMajor/Mi-
nor/Inc
HDecRevMajor/Mi-
nor/Inc
RFRevMajor/Mi-
nor/Inc
Capability (title)
Capability (data)
Subscription-Sta-
tus
ReasonCode
SuspendYear/
Month/ Day
Clear Non-Volatile
Memory Mode
Init Lock Passcode
* [Extended Channels] items shall be omitted when the attached module does not have overlay capability.
Display content
O S T S
O B 1 A
O B 1 B
O B 2 A
O B 2 B
O B T A
O B T B
O R 0 A
O R 0 B
M T X # # #
M H X # # #
M S X # # #
S M I X # # #
B B X # # #
H D X # # #
R F X # # #
C A P A B I L I
X # # # # #
S B S T
R E A S O N
S D # # #
C L E A R N V
I N I T C O D
(No.WA063<Rev.003>)29/31
[Extended channels]
Receiver State:(hex) "##"
Bit0: TB[otdm], Bit1:S2B[otdm]
X # # Bit2: S1B[otdm], Bit3: Pipe[LckB]
Bit4: TA [otdm], Bit5: S2A[otdm]
Bit6: S1A[otdm], Bit7: Pipe[LckA]
[Extended channels]
# # # OBER S1A: 0 ~ 100 (DEC) "###"
[Extended channels]
# # # OBER S1B: 0 ~ 100 (DEC) "###"
[Extended channels]
# # # OBER S2A: 0 ~ 100 (DEC) "###"
[Extended channels]
# # # OBER S2B: 0 ~ 100 (DEC) "###"
[Extended channels]
# # # OBER S1A: 0 ~ 100 (DEC) "###"
[Extended channels]
# # # OBER S1B: 0 ~ 100 (DEC) "###"
[Extended channels]
OBS0A: 0 ~ 100 (%) "###"
# # #
[Extended channels]
OBS0B: 0 ~ 100 (%) "###"
# # #
[Module Version]
# # # Module TypeID (hex) "######"
[Module Version]
# # # Module HW (hex) "######"
[Module Version]
# # # Module SW (hex) "######"
[Module Version]
# # # SXi (hex) "######"
[Module Version]
# # # BB (hex) "######"
[Module Version]
# # # HDec (hex) "######"
[Module Version]
# # #
RF (hex) "######"
Fixed string "Capability:"
T Y :
[Module Version]
# # #
Capability (hex) "########"
[Module Version]
X # #
Sub Status (hex) "##"
[Module Version]
X # #
Reason Code (hex) "##"
[Module Version]
# # #
Suspend (hex) "######"
