Kenwood DPX-U5130 Service Manual page 54

MODEL MARK MODEL
DPX500BT K0 DPX300U
DPX5130BTPT4 M3 KDPXU5130MM3
DPX-U5130 H1
Safe Symbol No. Parts No.
EXPLODED VIEW (CD MECHANISM: X92-6800-00) <130>
DM1 X94-2230-00
DM2 X94-2240-00
DPU1 QAL1521-001
FPC1 QAL1465-001
A LV45568-001A
B QYSPSGT1745ZA
C QYSPSPT2025MA
D N09-6108-15
E N09-6738-15
F N09-6921-05
G N19-2356-04
1 A10-5625-21
2 A10-5626-01
3 D10-7174-03
4 D10-7175-03
5 D10-7177-02
6 D10-7178-03
7 D10-7179-02
8 D10-7180-03
9 D10-7181-13
10 D10-7182-12
11 D10-7183-02
12 D10-7184-03
13 D10-7185-04
14 D10-7186-03
15 D10-7187-13
18 D13-3104-04
19 D13-3105-04
20 D13-3106-04
21 D13-3107-04
22 D13-3108-04
23 D13-3109-04
24 D13-3110-04
25 D13-3111-04
26 D13-3112-04
27 D13-3113-04
28 D13-3114-03
32 D23-0974-14
33 D39-0401-05
37 G01-4810-04
38 G01-4811-14
39 G01-4813-04
40 G01-4814-04
41 G01-4815-04
42 G01-4816-04
43 G01-4817-04
44 LV36813-501A
46 LV44555-001A
47 J11-0692-03
49 J19-7360-21
50 J90-1209-11
54 X94-2250-00
MARK MODEL
K1 DPX-U5130BT
M4 DPX405BT
Parts Name Description
MD CHASSIS ASSY
LOADING MOTOR ASSY
PICK UP
FPC
MINI SCREW
TAP SCREW M1.7 x 4.5mm
SCREW M2 x 2.5mm
TAPTITE SCREW M2 X 3.5mm
GEAR SCREW
MAIN SHAFT SCREW
ROLLER WASHER
OUTER CHASSIS
LOWER CHASSIS
DISC ARM L
DISC ARM R
SLIDER R
TRIGER SLIDER
SLIDER L
TIRIGER ARM
JOINT LEVER
ROLLER LEVER
CLAMP ARM
TRANSFER ARM
SL LOCK CAM
SL LCOK ARM
PICK LOCK ARM
HELICAL GEAR 1
TRANSFER GEAR
LOAD GEAR H
DRIVE GEAR
JOINT GEAR
WORM GEAR 2
HELICAL GEAR 2
LOAD GEAR V
PICK GEAR 1
PICK GEAR 2
RACK GEAR
ROLLER RETAIER L
DAMPER 1
DISC ARM SPRING
FLOATING SPRING F
TRIGER SPRING
LOAD SPRING
ROLLER SPRING
CLAMP SPRING
PICK SPRING
SUB GUIDE CAP
MAIN SHAFT
CLAMPER
GEAR HOLDER
DISC GUIDE
ROLLER ASSY
(No.WA063<Rev.003>)7/17
MARK MODEL MARK
M1 DPX-U5130 M2
E1 DPX305U E2
QTY Local
1
1
1
1
2
1
2
4
4
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
2
4
1
1
1
1
1
1
1
1
1
1
1
