Display Content - Kenwood DPX-U5130 Service Manual

Operation
Serial No. display
2 (Toggle)
All lights ON
Disc Eject number
of times display
3 (Toggle)
All lights ON
Information display
iPod verification IC
mount status
4 (Toggle)
display
All lights ON/TEST
5 (Toggle) Preout switch
DISP&ILLUMI
6 (Toggle)
color switching
DOP information
display
DOP information
display (steering
remote control)
SEARCH
(Toggle)
DOP information
display (steering
remote control)
All lights ON
Audio data Initialize

Display content

S N x x x x
E J C N T :
i P o d
i P o d
i P o d
i P o d
S W P R E
S W P R E
D O P
D O P - S T R
D O P - L V 1
A U D I O I N
(No.WA063<Rev.003>)17/31
Serial No. display (8-digit)
*Displays ASCII
x x x x
"********" is displayed if there is no registration
All lights ON (Switch with other display)
Display Disc Eject number of times.
x x x x x
MAX 65535 (times)
All lights ON (Switch with other display)
iPod verification IC mount status display
:
Blank: Verifying
: O K OK: Verification IC mounted
NG: Verification IC not mounted
: N G
**: Non-iPod support model
:
All lights ON (Switch with other display)
Switch Preout with toggle
R E A R
Initial value: Rear
S U B – W
All lights on by setting the RGB setting values indi-
cated below (switch with toggle).
Default value is white.
R=9; G=9; B=9 (white) → R=9; G=0; B=0 (red) →
R=0; G=0; B=9 (blue) → R=0; G=9; B=0 (green) →
R=9; G=9; B=9 (white)...
Since the [ACCENT] key for the model with BT is as-
signed to 2 colors (green and red), switch with toggle
according to the following order. (Lights off when the
LED is white, red when it's red, lights off when it's
blue, and green when it's green)
Default value: all lights off → red → all lights off →
green → all lights off
*Since the red and green LED for the [ACCENT] key
can not light on at once due to the circuit, these light
up alternately.
DOP information display
*Displays the DOP type in 3-digit value.
: x x x
*"----" is displayed for the commercial model.
DOP steering remote control information display
*Displays the remote control type in 3-digit value.
: x x x
*"----" is displayed for the commercial model.
DOP steering remote control information display
Voltage within the range of the remote control
threshold: OK
Other than above: NG
• 1xx: determination result of ch1
• 2xx: determination result of ch2
*OK/NG is determined when the steering remote
control jig is connected, and when the toggle opera-
x x 2 x x
tion is performed.
*Threshold range of the "OK" determination result is
the following:
PIN No.52 STG-REMO1 2.313V to 2.513V (718 to
780)
PIN No.53 STG-REMO2 0.855V to 1.055V (265 to
328)
When key is pressed, all lights ON/OFF with toggle
AUDIO setting value is re-set to default value of the
I T test mode.
When key is pressed, all lights ON/OFF with toggle
Details
