[set linkage]show in the appendix 9.1 about set alarm linkage.
[More configuration]
[Resolution]According to the front end of the highest resolution, set the difference of the resolution. For example:
the front 1080P, can Analysis of the four resolution of 1080P, 720P, D1, CIF .
Perimeter Intrusion detection configuration
When the equipment open the perimeter analysis function,can enter the perimeter setting page
by[Channel]-Alarm Type-Perimeter
[Channel]choose the channel of the perimeter analysis.
[Rule] click "+" add rule
[Set area]set current rule line what you choose
[direct]set the fold line rules to sure the detection direction.
Note: if there is no channel to analysis the perimeter detection,you can set the function by[Channel]-Alarm
Type-Perimeter
[rule]
click[+]make the new perimeter analysis rule.
Click the color box to set the line of color rule,show in the picture：
Click the rule name can modify the name.
Click the drop -down menuto choose the other rule,then can delete the rule.
Alarm input
6.4.3
[Main menu]-[Even t]
