4Automatically Added - CPcam CP-NVR-8CH User Manual

the front-end configuration.
There are two ways to login[IP Channel]
1、Living preview，click the button below [ IP Channel]
2、[Main Menu]-[Channel]-[ IP Channel]
Network channel management in the following page
[Check box]click the check channel,double click can deselect the check channel,Click the title bar to achieve
selection, double click can deselect all .
[Serial number]Display the network channel number to add equipment serial number.
[add、delete]click Delete the current network equipment.click add the network equipment.
[status]Show the current channel connection status： Connection is normal， ID or Password is wrong， the
equipment is offline， User is lock。
[IP address/domain name]Display the equipment's IP address/domain name.
[Port]Display the port number
[Web Port]Display the web port number.
[Agreement]Display the connection agreement.
[Edit]Configure the channel information，show in6.3.6
[The front-end configuration]Configuration front camera's parameters
We provide three ways to add device, automatically, searching,manually add the device.
6.3.4 Automatically added
No configuration, the device is automatically added.
[Main Menu]-[Channel]-[IP Channel]-[Open UPNP]
：
Note The device should support UPNP and should be in the same LAN.
