CPcam CPC-500 Owner's Manual

Dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Uživatelský manuál
-
ENG
Uživatelský manuál
-
ENG
CPC500W V1.2
Inteligent
ní
& Triplex
ní
Inteligent
ní
& Triplex
ní
4
-
kanálový
MPEG
-
2
4
-
kanálový
MPEG
-
2
digitální záznam
digitální záznam
500AW V1.0
DOVOZCE a DISTRIBUTOR do eské Republiky
DOVOZCE a DISTRIBUTOR do eské Republiky
VIAKOM s.r.o.,
Slovenská 891/5, 120 00 Praha 2
VIAKOM s.r.o.,
Slovenská 891/5, 120 00 Praha 2
www.viakom.cz
www.viakom.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPC-500 and is the answer not in the manual?

Questions and answers

Related Manuals for CPcam CPC-500

Summary of Contents for CPcam CPC-500

  • Page 1 Uživatelský manuál Uživatelský manuál CPC500W V1.2 Inteligent ní & Triplex ní Inteligent ní & Triplex ní kanálový MPEG kanálový MPEG digitální záznam digitální záznam 500AW V1.0 DOVOZCE a DISTRIBUTOR do eské Republiky DOVOZCE a DISTRIBUTOR do eské Republiky VIAKOM s.r.o., Slovenská...
  • Page 3 All the safety and operating instructions should be read before operation. The improper operation may cause permanent damage. ¡ This adaptor is only for this machine. Do not use it for other electronic products or it will damage other products. ¡...
  • Page 4 1. What do you get ? FEATURES PACKAGE CONTENT SPECIFICATIONS 2. Before Operation INSTALLATION GUIDE FRONT PANEL REAR PANEL 3. Basic Operation GETTING STARTED OPERATION RECORDING FUNCTION PLAYBACK FUNCTION 4. Detailed Menu Setup MAIN MENU MENU OPTIONS RECORD SETTING TIMER SETUP CAMERA SETTING DETECTION SETTING DISPLAY SETTING...
  • Page 5 R.E.T.R (Remote Event Trigger Recording) • Remote control via the internet • • Control PTZ camera • MPEG-2 compression format • Triplex function (record, playback and live at the same time) • USB Backup ( backup files by USB Sticker and USB HDD devices) •...
  • Page 6 Specifications are subject to change without notice. Video format NTSC/EIA or PAL/CCIR Hard disk storage IDE type, UDMA 66, supported 400 GB HDD Camera Input Signal Composite video signal 1 Vp-p 75 BNC, 4 channels Network Interface Ethernet (10/100 Base-T) Protocals TCP/IP, ICMP, SMTP, HTTP, FTP Resolution...
  • Page 7 1. Table below is an example of connecting the DVR to existing Observation System. 2. Install HDD (The compatible HDD models are listed in the following table). Please refer to page 46 Appendix A for installation instructions. Note: 1. The HDD must be installed before turning on the DVR. If HDD is not installed, the DVR would function as a 4 CH multiplexer.
  • Page 8 1. REMOVABLE HDD CARTRIDGE Please refer to page 47 Appendix #B. & KEYHOLE 2. CONTROL PANEL LED LIGHT The LED Light is ON under the following conditions. HDD : HDD is reading or recording. £ HDD Full : HDD is full . £...

  • Page 9: Video Input

    1. LAN Connect DVR by LAN cable. 2. EXTERNAL I/O  Controlled remotely by an external device or control system such as Video Web Server or PC.  Alarm input, external I / O expansion. 3. VIDEO INPUT (1-4) Connect to video source, such as camera. 4.
  • Page 10 1.Connect the AC power cord and plug into an electrical outlet. The Red LED indicator light will be ON and the DVR is in Standby mode. 2. Press the Power button. The POWER LED will turn from red to orange, and other red LED indicators will be turned ON. It takes approximately 5 to 15 seconds to boot the system with the message : “...

  • Page 11: Timer Recording

    The DVR offers 2 recording modes(Timer and Manual). Under the recording status, if power is off accidentally, the recorded video will still be stored in the HDD. DVR will return to previous original recording setting after power restores. The first character: ( Frame/Sec) A : 30 <NTSC>...

  • Page 12: Fast Forward) & F.r. (Fast Rewind)

    1. F.F. (FAST FORWARD) & F.R. (FAST REWIND) Increase the speed of Fast Forward and Rewind on the DVR by pressing the “FF” button. In the Play mode, press “  ” once to get 3X speed forward and press twice to get 45X speed,… and the maximum speed to reach 600X.
  • Page 13 % & Press “MENU” button to enter the main menu at first time. The default password is 000000. Pleas press “ENTER” menu six times to enter the menu when the password is default value. There are 10 options available in the Main Menu. RECORD -------- Record Scheduling CAMERA -------- Camera Setup DETECTION ---- Motion / Alarm Setup...

  • Page 14: Stop Record

    Press the “ ” “ ” “ ” “ ” buttons to move the cursor. & Press the “+” “-” buttons to change the digit. Press the “MENU” button to confirm the changes/ to exit the menu. 1. STOP RECORD The system will stop manual recording function during the recording period if the setting is “NO”.
  • Page 15 & ' " Press the “  ” “ ” “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the digit. Press the “MENU” button to confirm the changes/ to exit the menu. 1.

  • Page 16: Camera Default

    & Press the “  ” “ “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the option/digit. Press the “MENU” button to confirm the changes/ to exit the menu. 1. TITLE Assign a title to each channel. The default title is the camera’s number (Up to 8 characters). 2.
  • Page 17 Press the “ ” “ ” “ “ ” “buttons to move the cursor. Press the “+” “-” buttons to change the option. Press the “MENU” button to confirm the changes/ to exit the menu. 1. DET (DETECTION) The motion detection on each channel can be turned ON or OFF individually. 2.
  • Page 18 3. LS (Level Sensitivity) Comparing the difference between two images to allow the system to start motion detection function. Lower number = higher sensitivity for motion detection. The highest sensitivity setting is 02, the lowest sensitivity setting is 15. The default value is 06. 4.
  • Page 19 ! " # Press the “ ” “ ” “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the option/digit. Press the “MENU” button to confirm the changes/ to exit the menu. 1. TITLE DISPLAY Set the title showing on monitor.

  • Page 20: Full Screen

    " " " Press the “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the option. Press the “MENU” button to confirm the changes/ to exit the menu. 1. FULL SCREEN The full screen background picture display. 2.
  • Page 21 " Press the “ ” “ ” “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the option. Press the “MENU” button to confirm the changes/ to exit the menu. 1. NORM To set up the DWELL time period that each channel shows sequentially automatically on call monitor. The level is from 01 to 24 Sec or OFF.
  • Page 22 & Press the “ 4 4 4 4 ” “ 5 5 5 5 ” “ ” “ ” buttons to move the cursor. Press the “+” “-”buttons t0 change the setting Press the “MENU” button to confirm the changes/ to exit the menu 1.

  • Page 23: Motion Alarm

    ' ( ( ' " 1. BUZZER Set the BUZZER “ON”, it will buzz when event occurs. 2. EXT ALARM To set the EXT ALARM. It will be trigged by event occurrence when the setting is “ON”. 3. VLOSS ALARM To set the VLOSS ALARM.
  • Page 24 Press the “ ” “ ” buttons to move the cursor. Press the “ENTER” button to get into the submenu. The EVENT shows the recording list of different types. The VIDEO LOSS section lists the record of video loss. The ALARM LOG section lists the record of triggering by external I/O alarm. The MOTION LOG section lists the record of triggering by motion detection.
  • Page 25 " ( Press the “ ” “ ” “ ” “ ” buttons to move the cursor. Press the “+” “-” buttons to change the digit. Press the “ENTER” button to confirm the changes/ “MENU” to exit the menu. 1.Please press ENTER after set NEW ID, then the CURRENT ID and NEW ID will change to the same number which you have set.
  • Page 26 + , ( & Press the “ZOOM” button, It displays zoomed picture on main picture and a small inserted window. The inserted window contains a movable 1/4 view size of the appointed camera. The range is 2X. 2004 MAY-27 [THU] PM 01:45:37 Press the “ZOOM”...

  • Page 27: Event Search

    Press “SEARCH” button to play the recording. Select a channel for searching a video record. Press “ 4 4 4 4 ” “ 5 5 5 5 ” buttons to select camera. Press the “ENTER” button to get into menu/ submenu Press the “MENU”...
  • Page 28 3. LIST ALL List all video records. Press the “ 4 4 4 4 ” “ 5 5 5 5 ” buttons to select one record. Press the “ENTER” / “PLAY” buttons to display. 1. Y/M/D The Month and the Date display(Year/Month/Date). 2.
  • Page 29 Press “6 6 6 6 ” “ 7 7 7 7 ” buttons to select a channel or move to the next digit. Press “+” “-” buttons to change the digit. Step 1: Choose a certain camera by pressing “6 6 6 6 ” “ 7 7 7 7 ” buttons. Step 2: Enter the beginning and the end of time by pressing “+”...
  • Page 30 Direct Connect with PC CAMERA MONITOR Remote Connect Via Internet CAMERA MONITOR...
  • Page 31 1.Put the attached CD into a CD-ROM and it will start to install the application program into PC. 3.Choose destination location and press “Next”. 2. Press “Next”. 4.Set program shortcuts setting and press “Next”. 5.Press “Next” to begin to copy files 6.After the installation, there are 6 files and 1 folder in your assigned path (file folder) as below.
  • Page 32 Please enter the net work menu and get the IP Address of this DVR. 192.168.001.010 255.255.255.000 192.168.001.065 168.095.192.001 00060 Network setting for PC. (The instruction is based on Win XP O/S. If your O/S is Win 2000 or Win 2003, the setup procedure is similar to that of Win XP O/S) Click twice Local Area Connection Enabled...
  • Page 33 " 3 Click on “INTERNET PROTOCAL (TCP/IP)” and then select “Properties” to setup Choose “Use the following IP address” " 2 The last number of IP address between 1-255. Obtain an IP address automatically Use the following IP address: But it cannot the same as the DVR’s IP. 1 .
  • Page 34 " In DVR MENU / NETWORK set IP ADDRESS, GATEWAY, NET MASK, DNS and WEB PORT which are provided from your local ISP ( internet service provider ). For example After all network settings are finished, please connect DVR and static IP. Static IP "...
  • Page 35 1.Put the attached CD into a CD-ROM and it will start to install the application program into PC. 2. Press “Next”. 3.Choose destination location and press “Next”. 5.Press “Next” to begin copying files 4.Set program shortcuts setting and press “Next” 6.After the installation, there are 6 files and 1 folder in your assigned path (file folder) as below.
  • Page 36 + 6 !! 1. Click on free site “http://www.dyndns.org” ( please look at the example below, you can also apply DDNS in other DDNS web page) and “Account”. 2. Press “Create Account”. 3. Register the information and click on “Create Account” 4.After registering your account, you will receive an e-mail, which contains instructions to activate your account.
  • Page 37 NOTE : The following settings are different from router to router. Please read the instruction of your router thoroughly. 1.Connect PC and router (LAN end) LAN end POWER 2. Network setting for PC. (The instruction is based on Win XP O/S. If your O/S is Win 2000 or Win 2003, the setup procedure is similar to that of Win XP O/S) Click twice...
  • Page 38 4.Click on “INTERNET PROTOCAL (TCP/IP)” and then select “Properties” to setup 5.Choose “Obtain an IP address automatically” 6. Enter “Command Prompt”...
  • Page 39 7. In the setting window, enter “ ipconfig” to write down router’s gateway(e.q. 192.168.1.1) 8. Close the window in the above step. Enter the IP address ( router’s gateway : 192.168.1.1 ) to log in to the router from internet explore. And then enter the login web page and key in the router’s user name and password.
  • Page 40 1. Press “INTERNER PORT” and choose your WAN type (e.q. PPPoE), and then enter your “User Name” and “Password” of dialing up to dynamic IP. Press save after you finish the set up. test test 2. Press “LOCAL PORT” and set “Start IP address” and “Number of IP address”. (For example, if the IP address of DVR is 192.168.1.10, then 10 is excluded from the setting range) Press save...
  • Page 41 4. In “ADVANCED SETUP / Dynamic DNS”. Key in the “DNS Account”, “User Name” and “Password” that you applied in step 3. Press save after you finish the set up. test 3 6 " In DVR MENU / NETWORK set SERVER IP, GATEWAY, NET MASK, DNS and WEB PORT. Please get the number of IP ADDRESS, NETMASK, GATEWAY, DNS, PORT, LOAD DEFAULT from your ISP company.
  • Page 42 !& * 1. Change PC network setting to the original setting and link PC to the internet. 2. Click twice and enter your User name, Password and host (Note : The default User Name and Password are both “admin”). Then click OK to connect. test.
  • Page 43 Follow the steps for connection at your client site (remote site). Click twice to enter Login setup (please refer to page 18“software installation”) Key in “User Name” and “ Password”. Click “OK” to establish the connection. If you could see the video screen as following, you have been connecting successfully to the server. 2004-DEC-23 [ THU ] 10:42:32 Aa 001.9 GB O/W CAMERA01 CAMERA02...
  • Page 44 B. Digital device control panel 1. CH1-4 * + / - : 2. PIP/+, QUAD/- * Press “+” or “-” to change the default value. 3. Zoom, Lock, Record, Search **TURBO: Activate the turbo button when you would like to shift the 4.

  • Page 45: System Config

    Click “SYSTEM CONFIG” for advanced setting. NOTE : Apply-- After changing all setting, press “apply” to refresh the data. Reboot-- SYSTEM CONFIG Press this button to restart setting. Set up the user’s account( Max 10 accounts) , password and authority ( Max 5 accounts on line at the same time) . 1.User’s level: SUPERVISOR-control all the functions HIGH LEVEL-control advanced functions...
  • Page 46 & When the alarm is triggered, the video server program will capture the instant picture and e-mail the captured image to the assigned recipients. 1. Get all the data from the ISP company or by mailing to the server supplier.(SMTP server) 2.
  • Page 47 Upgrade the firmware and get the online users’ information. NOTE :Do not reboot the DVR while it is upgrading the firmware. 1.Firmware Version : The current firmware version. 2. Find and upgrade Firmware: Please get the firmware from your agent and save it in your PC or USB. Press “Find”...
  • Page 48 You can also connect Video Web Server via browser. This function is suitable in both WIN 2000 and WIN XP ( WIN XP is preferable to WIN 2000) 0 0 0 0C C C C Enter IP address that you want to connect.(example) http://61.66.138.74 + + + + C C C C Enter your Username and Password to login Video Web Server.
  • Page 49 When malfunction occurs, it may not be serious and can be corrected easily. The table below describes some typical problems and their solutions. Please check them before calling your DVR dealer. PROBLEM SOLUTION No power Check power cord connections. Confirm that there is power at the outlet. Not working when pressing any Check if it is under Key Lock mode.
  • Page 50 " " !, : - -!! Follow the steps carefully in order to ensure correct installation. The compartment located on the front panel of the DVR is the removable Cartridge, in which you insert the HDD. The various parts of the Cartridge are labeled for your reference. ***Note: Users need to set the HDD on the Master mode for the system detecting.*** Step 1 Connect the connector with the HDD (refer to Picture 1).
  • Page 51 " " !, : " - -!! A ( locked ) B ( unlocked ) Step 1 Open the cap Step 2 Unlock the cabinet by turning the key anti-clockwise Step 5 Step 4 Loosen all screws on Step 3 Pull out the cartridge the Cartridge Note: 1.
  • Page 52 " " !, !: " PIN 3, 4, 5, 6 ALARM INPUT To connect wire from ALARM INPUT (PIN 3, 4, 5, 6) to GND ( PIN 9 ) connector. When alarm has been triggered, signal becomes “Low”, and it will stop all alarm activities. Under normal operation, signal remains “High”. PIN 7.
