3.3 Control Parameters Cn-□□
Parameter
Function
No.
Cn-01
Cn-02
Cn-03 Max. Output Voltage
Cn-04
V/F
Pattern
Setting
Cn-05
Voltage At Middle
Cn-06
Output Frequency
Cn-07
Cn-08
Output Frequency
Cn-09 Motor Rated Current
No Load Current Of
Cn-10
Motor
Cn-11 Rated Slip Of Motor
Parameter
Cn-12
Resistance Of Motor
Torque Compensation
Cn-13
DC Injection Braking
Cn-14
Starting Frequency
Cn-15 DC Braking Current
DC
Braking
DC Injection Braking
Function
Cn-16
DC Injection Braking
Cn-17
Frequency Command
Cn-18
Frequency
Limit
Frequency Command
Cn-19
Cn-20
Frequency
Jump
Cn-21
Name LCD display (English)
Input Voltage
Max. Output
Frequency
Max. Voltage
Frequency
Middle Output
Frequency
Min Output
Frequency
Voltage At Min.
Motor
Line-To-Line
Of Core Loss
Time At Stop DC Braking Stop Time
Time At Start DC Braking Start Time
Upper Bound
Lower Bound Freq. Cmd. Low Bound
Frequency Jump
Point 1
Frequency Jump
Point 2
Cn-01= 220.0V
Input Voltage
Cn-02= 060.0Hz
Max. O/P Freq.
Cn-03= 220.0Hz
Max. Voltage
Cn-04= 060.0Hz
Max. Volt Frequency
Cn-05= 003.0Hz
Middle O/P Freq.
Cn-06= 014.9V
Middle Voltage
Cn-07= 001.5Hz
Min O/P Freq.
Cn-08= 007.9V
Min. Voltage
Cn-09= 0003.3A
Motor Rated I
Cn-10= 30％
Motor No-Load I
Cn-11= 0.0%
Motor Rated Slip
Cn-12= 05.732Ω
Motor Line R
Cn-13= 0064W
Core Loss
Cn-14= 01.5Hz
DC Braking Start F
Cn-15= 050％
DC Braking Current
Cn-16= 00.5s
Cn-17= 00.0s
Cn-18= 100％
Freq.Cmd. Up Bound
Cn-19= 000％
Cn-20= 000.0Hz
Freq. Jump 1
Cn-21= 000.0Hz
Freq. Jump 2
44
Setting
Setting range
Unit
*2
150.0∼255.0V 0.1V 220.0V
50.0∼400.0Hz 0.1Hz 60.0Hz
*2
0.1∼255.0V 0.1V 220.0V
0.1∼400.0Hz 0.1Hz 60.0Hz
0.1∼400.0Hz 0.1Hz
*2
0.1∼255.0V 0.1V
0.1∼400.0Hz 0.1Hz
*2
0.1∼255.0V 0.1V
*3 0.1A
0∼99％ 1％
0∼9.9％ 0.1%
0∼65.535Ω 0.001Ω 5.732
0∼65535W 1W
0.1∼10.0Ｈz 0.1Hz
0∼100％ 1％
0.0∼25.5s 0.1s
0.0∼25.5s 0.1s
0∼109％ 1%
0∼109％ 1%
0.0∼400.0Hz 0.1Hz
0.0∼400.0Hz 0.1Hz
Factory Ref.
Setting Page
*1
48
*1
3.0Hz 48
*1
14.9V
1.5Hz
*1
7.9V
*4
3.3A 48
30％ 49
0.0% 49
*4
50
*4
64
1.5Hz
50％
50
0.5s
0.0s
100％
51
0％
0.0Hz
51
0.0Hz
