TECO speecon 7200ma Instruction Manual page 48

Parameter
Function
No.
Cn-45
Cn-46 Pole no. of Motor
ASR Proportional
Cn-47
Cn-48 ASR Integral Gain 1
ASR Proportional
Cn-49
Speed
feedback
Cn-50 ASR Integral Gain 2
control
Cn-51 ASR Upper Bound
Cn-52 ASR Lower Bound
Excessive Speed
Cn-53 Deviation Detection
Overspeed Detection
Cn-54
PID Integral Upper
Cn-55
PID
Control
PID Primary Delay
Cn-56
Motor Line-to-Line
Cn-57
Motor Rotor Equivalent
Cn-58
Sensorless
Vector Cn-59
Control
Cn-60
Inductance (Lm)
Slip Compensation
Cn-61
*1 These are for a 220V class inverter. Value(*1) for a 440V class inverter is double.
*2 These are for a 220V class inverter. Value(*2) for a 440V class inverter is double.
*3 The setting range is 10% ~200% of the inverter rated current.
*4 The factory setting values will vary based upon the inverter capacity selection (Sn-01)
value. In this case, the setting is for 4-pole, 220V, 60Hz, 1Hp TECO standard induction
motors.
Name LCD display (English)
PG Parameter
Gain 1
Gain 2
Level
Level
Bound
Time Constant
Resistance (R1)
(R2)
Resistance
Motor Leakage
Inductance (Ls)
Motor Mutual
Gain
Cn-45= 0000.0
PG Parameter
Cn-46= 04P
Motor Pole
Cn-47= 0.00
ASR Gain 1
Cn-48= 01.0s
ASR Intgl. Time 1
Cn-49= 0.02
ASR Gain 2
Cn-50= 01.0s
ASR Intgl. Time 2
Cn-51= 05.0％
ASR Up Bound
Cn-52= 00.1％
ASR Low Bound
Cn-53= 10％
Sp.Deviat. Det.Level
Cn-54= 110％
Over Sp.Det. Level
Cn-55= 100％
PID I-Upper
Cn-56= 0.0s
PID Filter
Cn-57= 02.233Ω
Mtr LINE_R
Cn-58= 01.968Ω
Mtr ROTOR_R
Cn-59= 9.6mH
Mtr LEAKAGE_X
Cn-60= 149.7mH
Mtr MUTUAL_X
Cn-61= 1.00
SLIP GAIN
46
Setting
Setting range
Unit
0.0∼3000.0P/R 0.1P/R 0.0P/R
2∼32P 2P
0.00∼2.55 0.01
0.1∼10.0S 0.1s
0.00∼2.55 0.01
0.1∼10.0S 0.1s
0.1∼10.0％ 0.1％
0.1∼10.0％ 0.1％
1∼50％ 1％
1∼120% 1％
0∼109％ 1％
0.0∼2.5s 0.1s
0.001∼60.000Ω 0.001Ω
0.001∼60.000Ω 0.001Ω
0.01∼200.00mH 0.01mH 9.6mH
0.1∼6553.5mH 0.1mH
0.00∼2.55 0.01
Factory Ref.
Setting Page
4 P
0.00
60
1.0s
0.02
1.0s
5.0%
0.1%
60
10%
110%
100%
61
0.0s
*4
2.233Ω
*4
1.968Ω
61,
*4
62
*4
149.7mH
1.00
