3. Parameter Setting

3.1 Frequency command (in Multi-speed operation)

Under the DRIVE mode, the user can monitor the parameters and set their values.
Parameter
Name
No.
An-01 Frequency Command 1
An-02 Frequency Command 2
An-03 Frequency Command 3
An-04 Frequency Command 4
An-05 Frequency Command 5
An-06 Frequency Command 6
An-07 Frequency Command 7
An-08 Frequency Command 8
An-09 Frequency Command 9
An-10 Frequency Command 10
An-11 Frequency Command 11
An-12 Frequency Command 12
An-13 Frequency Command 13
An-14 Frequency Command 14
An-15 Frequency Command 15
An-16 Frequency Command 16
Jog Frequency
An-17
Command
*1. At factory setting, the value of "Setting Unit" is 0.01Hz.
*2. The displayed "Setting Unit" can be changed through the parameter Cn-28.
LCD Display (English)
An-01= 000.00Hz
Freq. Cmd. 1
An-02= 000.00Hz
Freq. Cmd. 2
An-03= 000.00Hz
Freq. Cmd. 3
An-04= 000.00Hz
Freq. Cmd. 4
An-05= 000.00Hz
Freq. Cmd. 5
An-06= 000.00Hz
Freq. Cmd. 6
An-07= 000.00Hz
Freq. Cmd. 7
An-08= 000.00Hz
Freq. Cmd. 8
An-09= 000.00Hz
Freq. Cmd. 9
An-10= 000.00Hz
Freq. Cmd. 10
An-11= 000.00Hz
Freq. Cmd. 11
An-12= 000.00Hz
Freq. Cmd. 12
An-13= 000.00Hz
Freq. Cmd. 13
An-14= 000.00Hz
Freq. Cmd. 14
An-15= 000.00Hz
Freq. Cmd. 15
An-16= 000.00Hz
Freq. Cmd. 16
An-17= 000.00Hz
Jog Freq. Cmd.
35
Setting
Setting Range
Unit
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 0.00Hz
0.00∼400.00Hz 0.01Hz 6.00Hz
*1
An -□□
*2
Factory Ref.
Setting Page
82,97,
98
84
