■ Example of display (use
items/contents)
Description
． Display
Frequency Command
． Display
Moniter Contents *1
． Display
Output Current
． Display
Output Voltage
． Display
DC Voltage
． Display
Output Voltage
． Display
Output Current
*1 The monitor contents can be selected by the setting of Bn-12 and Bn-13
and
Key Sequence
Freq. Cmd. 60.00Hz
Freq. Cmd. 60.00 Hz
DSPL
Freq. Cmd. 60.00 Hz
Freq. Cmd. 60.00 Hz
Freq. Cmd. 60.00 Hz
Freq. Cmd. 60.00 Hz
Freq. Cmd. 60.00 Hz
34
keys to display monitored
Digital Operator
Display
TECO
O/P Freq. 60.00 Hz
O/P I 12.5 A
O/P Volt. 220.0 V
DC Volt. 310.0 V
O/P Volt. 220.0 V
O/P I 12.5 A
Remark
