CKT NO.
Part no.
C804
5233327191
C805
5213547112
C805A
5232310301
C806
5216122112
C807
5215447112
C807A
5232310301
C808A
5232310301
C808
5215447112
C809
5233333191
C809A
5213310212
C809B
5233333191
C811
5236310491
C811A
5232327191
C812A
5233318191
C813
5233318191
C814
5233333191
C815
5210313400
C816
5233310301
C817
5213322091
C819
5236310491
C822
5230105401
C823
5230105401
Description
CE 1KV 270PF K
EL 35V 470UF M
CE 500V 10000PF K
EL 100V 220UF M
EL 25V 470UF M
CE 500V 10000PF K
CE 500V 10000PF K
EL 25V 470UF M
CE 1KV 330PF K
EL 16V 1000UF M
CE 1KV 330PF K
BL 50V 0.1UF Z
CE 500V 270PF K
1KV 180PF K
1KV 180PF K
CE 1KV 330PF K
EL 400V 220UF M
CE 1KV 10000PF K
EL 16V 220UF M
BL 50V 0.1UF Z
CE 400V 2200PF M
CE 400V 2200PF M
CKT NO.
Part no.
C825
5230105501
C826
5230105501
C827
5213310191
C829
5213310191
C830
5270106301
C831
5213633991
C832B
5230105401
C834
5232322291
C838
5233310291
C840
5213633991
C862
5247047191
C863
5231322291
C864
5275122391
C866A
5213547091
C870
5213410212
C871
5232310301
C872
5213310191
C873
5236310491
C874A
5213447091
C876
5213347091
43
Description
CE 400V 4700PF M
CE 400V 4700PF M
EL 16V 100UF M
EL 16V 47UF M
ME 250V 0.47UF M
EL 50V 3.3UF M
CE 400V 2200PF M
CE 50V 2200PF K
CE 1KV 1000PF K
EL 50V 3.3UF M
CE 50V 470PF J
CE 50V 2200PF K
ME 63V 22000PF J
EL 35V 47UF M
EL 25V 1000UF M
CE 500V 10000PF K
EL 16V 100UF M
BL 50V 0.1UF Z
EL 25V 47UF M
EL 16V 47UF M
