Nokia 447ZiPlus Service Manual page 35

17” colour monitor
Table of Contents

Advertisement

(8) MICRO CONTROL FUNCTION ABNORMAL
(9)HORIZONTAL WIDTH CONTROL ABNORMAL
MICRO CONTROL
ABNORMAL
Is the
No
control function
working ?
Yes
PWB-0171
key control board
H. SIZE ABNORMAL
Is H.size
No
control function
working
Yes
Check
Q408, Q408A, Q502
Is the sync
signal on Pin
39/40 normal
?
Yes
Check 5V on Pin 5 of I501
Check X510, D506, C506
Is voltage at
No
the base of
Q467 normal
?
Yes
Check Q467, Q468,
Q470, C471, L471
33
No
Check Q550,
Q556
Check Q502, I501
