CKT NO.
Part no.
Q407(RB)
6626004000
Q408(RA)
6621015332
Q408(RB)
6621015335
Q408A(RA)
6621015332
Q408A(RB)
6621015335
Q409(RA)
6621015332
Q409(RB)
6621015335
Q423(RA)
6626003900
Q423(RB)
6626004000
Q423(RC)
6626006500
Q429(RA)
6622013330
Q429(RB)
6622013331
Q433(RA)
6621006212
Q433(RB)
6621006207
Q438(RA)
6621015332
Q438(RB)
6621015335
Q439
6623002050
Q440(RA)
6626000700
Q440(RB)
6626000701
Q466(RA)
6621015332
Q466(RB)
6621015335
Q467
6623002050
Q468
6623002050
Q470(RA)
6622018600
Q470(RB)
6622010603
Q480
6621026430
Q489
6621026430
Q495(RA)
6621015332
Q495(RB)
6621015335
Q497
6624012330
Q501(RA)
6621015332
Q501(RB)
6621015335
Q502(RA)
6621015332
Q502(RB)
6621015335
Q550(RA)
6621015332
Q550(RB)
6621015335
Q556(RA)
6621015332
Q556(RB)
6621015335
Q580
6621026130
Description
TRANSISTOR FET MOS N-CH 2SK2161
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR FET MOS 2SK2160
TRANSISTOR FET MOS N-CH 2SK2161
TRANSISTOR FET MOS FS10KM-5
TRANSISTOR NPN LF 2SD667C-TZ
TRANSISTOR NPN LF 2SD667AC
TRANSISTOR NPN HF BU4522AX
TRANSISTOR NPN HF 2SC5129
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR PNP HF 2SA1015Y
TRANSISTOR FET MOS IRF730FI
TRANSISTOR FET MOS 2SK2679 400V 5.5A
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR PNP HF 2SA1015Y
TRANSISTOR PNP HF 2SA1015Y
TRANSISTOR NPN LF TIP122
TRANSISTOR NPN LF TIP122
TRANSISTOR NPN HF BF422
TRANSISTOR NPN HF BF422
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR PNP HF BF423 TO-92
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF 2SC1815Y
TRANSISTOR NPN HF H945P
TRANSISTOR NPN HF BF420
48
