3.9 Rotary switch setting: Info

Parameter
T-HS
T-HS des
T-Outside
T-DHW
T-DHW des
T-Return
Flow Rate
T-HC
T-HC Setpoint
Water Pressure
Runtime Compres-
sor
Runtime Pump
Qboh
Qchhp
Qsc
Qch
QWP
Qdhw
SW Nr CUI
SW Nr Controller
SW Nr. RTX RT
Mixer Position
Tab. 3-8 Parameter in rotary switch setting "Info"
FA ROTEX RoCon HP - 03/2013
Designation
The current (flow) temperature of the heat generator is displayed.
The current set temperature of the heat generator is displayed in °C with one dec-
imal point.
The current outdoor temperature is displayed in °C with one decimal point.
The current temperature of the hot water storage tank is displayed in°C mit with
one decimal point. If no hot water function is activated, "- - -" is displayed.
We display the current set temperature for the hot water generation in °C with one
decimal point. If no hot water function is activated, "- - -" is displayed. The current
set value is here always the maximum value of all requirements relevant to this hot
water circuit.
The current return temperature of the heat generator in °C with one decimal point
is displayed. If there is no corresponding sensor connected to the heat generator,
"- - -" is displayed.
The filtered value of the current volume flow is displayed.
The temperature of the direct heating circuit is displayed in °C with one decimal
point.
The set (flow) temperature of the direct heating circuit is displayed in °C with one
decimal point.
The current water pressure is displayed in bar.
The running time of the compressor is displayed in h.
The running time of the pump is displayed in h.
The quantity of heat in the reserve heating for hot water generation is displayed in
kWh.
The quantity of heat in the reserve heating for heating is displayed in kWh.
The quantity of heat in the heat pump for cooling is displayed in kWh.
The quantity of heat in the heat pump for heating is displayed in kWh.
The total amount of heat in the heat pump is displayed in kWh.
The quantity of heat for hot water generation is displayed in kWh.
The software and version of the operating unit is displayed.
The software number and the version of the regulating board are displayed.
The software number and the version of the modbus board are displayed.
The current position of the 3UV1 mixer is displayed in %.
3 x Parameter settings
Access Setting range Factory
Min / Max setting
BE HF
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
S S
Incre-
ment
0.1 °C
0.1 °C
0,1 °C
0,1 °C
0.1 °C
l/h
0.1 °C
0,1 °C
0.1 bar
h
h
0.1 kW
0.1 kW
0.1 kW
0.1 kW
0.1 kW
0.1 kW
-
-
-
-%
