3.4 Rotary switch setting: Operating Mode

Parameter
Standby
Reducing
heating
cooling
Summer
Automatic 1
Automatic 2
Tab. 3-3 Parameter in rotary switch setting "Operating Mode"

3.5 Rotary switch setting: Set Temp Day

Parameter
T-Room des 1
T-Room des 2
T-Room des 3
Tab. 3-4 Parameter in rotary switch setting "Set Temp Day"

3.6 Rotary switch setting: Set Temp Night

Parameter
T-Reduced
T-Absence
Tab. 3-5 Parameter in rotary switch setting "Set Temp Night"

3.7 Rotary switch setting: DHW Set Temp

Parameter
T-DHW 1 des
T-DHW 2 des
T-DHW 3 des
Tab. 3-6 Parameter in rotary switch setting "DHW Set Temp"
FA ROTEX RoCon HP - 03/2013
Designation
In this operating mode all the internal functions are switched off. Frost protection
remains active and a blocking protection for the pump is guaranteed. Attention:
This operating mode does not mean that all outputs are always potential-free.
The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised setback temperature.
The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised day set room temperature (heating).
The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised day set room temperature (cooling).
In this operating mode the internal heating circuit is switched off. Frost protection
remains active and a blocking protection for the pump is guaranteed. Hot water
generation works normally.
The internal heating circuit regulates according to the first parametrised timer pro-
gramme with the individual set day room temperatures.
The internal heating circuit regulates according to the second parametrised timer
programme with the individual set day room temperatures.
Designation
The set value of the room temperature in °C with one decimal point that applies to
the 1st. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
The set value of the room temperature in °C with one decimal point that applies to
the 2nd. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
The set value of the room temperature in °C with one decimal point that applies to
the 3rd. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
Designation
We adjust the set value of the setback room temperature in °C with one decimal
point which applies to the timer programmes Automatic 1 and Automatic 2.
We adjust the set value of the setback room temperature in °C with one decimal
point which applies to the timer programmes Away and Vacation.
Designation
We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 1st. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 2nd. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 3rd. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
3 x Parameter settings
Access Setting range Factory
Min / Max setting
BE HF
E E
E E
E E
E E
E E
E E
E E
Access Setting range Factory
Min / Max setting
BE HF
E E 5 - 40°C 20 °C
E E 5 - 40°C 20 °C
E E 5 - 40°C 20 °C
Access Setting range Factory
Min / Max setting
BE HF
E E 5 - 40°C 15 °C
E E 5 - 40°C 15 °C
Access Setting range Factory
Min / Max setting
BE HF
E E 10 - 70°C 48 °C
E E 10 - 70°C 48 °C
E E 10 - 70°C 48 °C
Incre-
ment
Incre-
ment
0.5 K
0.5 K
0.5 K
Incre-
ment
0.5 K
0.5 K
Incre-
ment
0.5 K
0.5 K
0.5 K
23
