3 x Parameter settings

3.8 Rotary switch setting: Time Program

Parameter
Party
Away
Vacation
Holiday
HC Program 1
HC Program 2
DHW Program 1
DHW Program 2
Circulation Time
Tab. 3-7 Parameter in rotary switch setting "Time Program"
24
Designation
With this operating mode we can set a one-off time for the temporary heating time
extension of the internal heating circuit.
With this operating mode we can set a one-off time for the temporary regulation to
the parametrised absence temperature.
The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised absence temperature (parameter T-Reduced).
A calendar function can be used to enter a time period for the absence.
A calendar function can be used to enter a time period for presence.
In this menu we can parametrise the 1st. timer programme for the internal heating
circuit. 3 heating blocks with a resolution of 15 minutes can be set. A separate entry
for each weekday is possible.
Also, blocks of Monday to Friday, Saturday to Sunday and Monday to Sunday can
be parametrised.
In this menu we can parametrise the 2nd. timer programme for the internal heating
circuit. 3 heating blocks with a resolution of 15 minutes can be set. A separate entry
for each weekday is possible.
Also, blocks of Monday to Friday, Saturday to Sunday and Monday to Sunday can
be parametrised.
In this menu we can parametrise the 1st. timer programme for hot water genera-
tion. 3 heating blocks with a resolution of 15 minutes can be set. A separate entry
for each weekday is possible.
Also, blocks of Monday to Friday, Saturday to Sunday and Monday to Sunday can
be parametrised.
In this menu we can parametrise the 2nd. timer programme for hot water genera-
tion. 3 heating blocks with a resolution of 15 minutes can be set. A separate entry
for each weekday is possible.
Also, blocks of Monday to Friday, Saturday to Sunday and Monday to Sunday can
be parametrised.
In this menu we can parametrise a timer programme for the circulation pump. 3
heating blocks with a resolution of 15 minutes can be set. A separate entry for each
weekday is possible.
Also, blocks of Monday to Friday, Saturday to Sunday and Monday to Sunday can
be parametrised.
Access Setting range Factory
Min / Max setting
BE HF
E E
E E
E E
E E
E E
E E
E E
E E
E E
