10. Specification

Operating Voltage:
Battery type:
Current drain (ON):
Current drain (OFF):
Output voltage regulated:
Max. output current:
Dropout voltage:
Signal resolution:
Output framerate:
Display:
Servo sockets:
Channels
Telemetrie:
Size:
Weight incl. Switch and screen: 115g
Temperature range:
EMV approval:
CE approval:
4.0V - 9.0V
2s LiPo/LiIon, 2s LiFePo, 5s NiMH/NiCd,
approx. 99mA
approx. 3μA
5.9V and/or 7.4V
Peak 2 x 20A
0.3V
0.5μs
12ms, 15ms, 18ms, 21ms
OLED 128x64 pixels, graphic
15
max. 18
Futaba, Jeti, Spektrum, Hott, M-Link,
JR DMSS
93x67x19 mm
-30°C to +75°C
EN 55014-1:2006
2004/108/EG
-32-
