12 SPARE PART KITS
Item No.
Description
1
Cover Assembly
2a
PC Board Assembly
2b
PC Board Assembly with analog feedback
3
Repair kit for Logix 500-Relay Module Assembly
4
Repair kit for Potentiometer Assembly
5
Position Feedback Assembly
8
Follower Arm Assembly
Mounting Kits
Item No.
Description
–
IEC 534 part 6 (Valtek 2000, Kämmer KA, Kämmer KP, and standard NAMUR linear valves)
–
Rotary VDI/VDE 3845 (DIN ISO 5211)
Gauge Kits
Item No.
Description
–
2 gauge set, 6 bar / 4 bar, brass, nickel plated
–
2 gauge set, 6 bar / 4 bar, stainless steel
Yellow
White
Black
Max. stroke 65 mm
Max. stroke 110 mm
Part-No.
H10114000
H10114001
H10011500
H10011600
H194500003
H194512001
H194512002
Part-No.
H192685001
H194984001
Part-No.
H179379013
H179379015
