Chapter 4: Software

2. On enabling "Screen Rotation Monitor", you will see a screen like

below:

3. Choose rotate function (0°, 90°, 180°, 270°) in the 3rd party software.

The calibration screen will appear automatically. Touch this point and

rotation is mapped.

NOTE: Rotate function is disabled if you use Monitor Mapping.

Touchscreen Configuration of PenMount

Digitizer Driver

With PenMount Windows Universal V2.2.0.283 and the later versions, since

the touchscreen is automatically installed as a digitizer device in Windows

Vista/7, the functions built in Windows Vista / 7 such as rotation, multi-

monitor, flicks, and context menu function (which launches a context menu

by user's long-pressing on touchscreen rather than clicking the right mouse

button or pressing the application key on the keyboard) will be supported.

To configure touchscreen in PenMount Digitizer driver:

Double-click on the PenMount Control Panel icon

on the Desktop.

On PenMount Control Panel you are able to see the device of PenMount

6000 USB/RS-232 detected by your system under Device tab. Select a

device and click the Configure button.
