Chapter 2: Jumpers and Connectors
CANBus Impedance Control
Connector location: SW4
1 2
Pin
Function
1~2 ON
120 OHM
1~2 OFF
Non
Copyright © 2016 NEXCOM International Co., Ltd. All rights reserved
GPIO High-Low Switch
Connector location: SW5
1 2 3 4
Pin
Definition
1~2 ON
GPI Pull-High
3~4 ON
GPO Pull-High
16
VMC 3020 User Manual
