Chapter 3: Installation of SSD and Modules
4.
a. Place the white washers on the screws.
b. Insert the SATA power and signal cable onto the connectors marked
in red.
c. Attach cable onto SSD.
d. Fix (screws + white washer) the SSD with bracket onto the mounting
location, marked in red.
Copyright © 2016 NEXCOM International Co., Ltd. All rights reserved
27
VMC 3020 User Manual
