Step 8: Assembly of the console and setting the supporting feet
(1) Loosen the four pre-mounted
screws (G1) from the console (G).
(2) Connect the console cables (D1,
D2, D14 & D16) and the heart rate
cable (D4) from the console mast
with the console.
Note: Make sure that the cables
are properly connected with each
other. Slide the excess cable into
the casing and the console mast (D).
(3) Mount the console (G) on the
console mast (D) with the four
screws (G1).
(4) Use the adjusting screws under
the side parts in order to level out
any unevenness in the floor.
Step 9: Locking the pedal bars (B1 and B2)
The pedal bars should always
be locked if the equipment is
not being used.
To do this, turn the knob (A3) to
the "LOCK" position in order to
lock the pedal bars (B1 and B2)
and avoid possible injuries.
Note: Never lock the pedal bars if
the equipment is still moving, but
rather only when the equipment
has come to a complete standstill.
