3.2
Assembly instructions
Before starting assembly, look carefully through the individual assembly steps shown
and assemble the equipment in the order indicated.
Caution while unpacking:
Place box flat on the ground, remove cover. Unpack handles, side supporting bars,
pedal bars and operating instructions. Remove the upper foam parts (1) and (2) and
take out the console, console supporting tube, console mast, pedal supporting bars
and hardware bag. First leave the main frame (A) and lower foam parts (3) and (4) in
the box.
Note: For safety reasons, the pedal bars are just to be released with the respective
control knob once you are asked to do so at the end of the instructions.
Foam (1)
Foam (2)
EX90 PLUS
14
