The intercom is deactivated automatically when you enter
SPLIT mode.
o Push the ICS button until the green LED lights up CRW to
restore intercom between pilot and copilot.
o Intercom between crew and passengers is not possible in split
mode
The spatial component of IntelliAudio ® is defeated in split mode.
To exit SPLIT mode, simply select C1 or C2 XMT button

COM Audio Selector (3)

Communication audio from the other radio, not selected for transmit,
can be heard by pressing the associated RCV button. You will always
hear the audio from the selected transceiver.
Swap Mode (Switch from Com 1 to Com 2 remotely)
With an optional yoke mounted, normally open momentary switch,
the pilot can change from the current Com transceiver to the other by
pressing this switch. To cancel "Swap Mode," either press the yoke
mounted switch again, or select a different Com with the XMT but-
tons.
IntelliAudio® Dimensional Audio
Various audio signals are presented to the DSP and processed to
"appear" in a different location to the crew."Multi-Talker" (US Patent
#7,391,877) specifies up to nine locations. This helps the crew to bet-
ter comprehend speech by locating it in a manner easier differentiated
by the human brain.
Intercom and other audio is not spatially processed, only the pilot and
copilot VHF COM audio.
The spatially processed dimensional sound in the PDA360EX can be
adjusted to accommodate the user preferences.
This adjustment allows the Spatial Audio inputs to be "relocated" on
any of nine (9) defined "Head Related Transfer Function" (HTRF)
locations.
Page 4 202-360-0000 PDA360EX Pilot Guide R1
