Set IOChannel

Set IOChannel IOExtension

Description Configures the I/O extension options that allow you to connect the Digital Input
User Level Admin
Syntax
Options
148
clear-mode
Specifies whether an activated alarm must be
the input drops below the specified value (when
the specified value (when
clear-level
Specify that value that will clear an alarm, the measurement is based on the
that you specify. This value must not fall within the scope of the value used to
Range
trigger an alarm.
email
Sends an email alert to an email account(s) set up in the Server settings (the
Alert settings are not used with this feature) when an alarm is triggered or cleared. The
email alert data includes the severity level and the value that caused the alarm to trigger
or clear. The Email Alert is associated with
snmp
Sends an SNMP trap when an alarm is triggered or cleared. The trap consists of the
severity level and whether the alarm was triggered or cleared.
syslog
Sends a message to syslog when an alarm is triggered or cleared. The syslog entry
includes the severity level and the value that caused the alarm to trigger or clear. The
syslog message is associated with
channel or input serial signal pin (when the line is configured for signal-io) to Digital
Output/Relay channels or output serial signal pins (when the line is configured for
signal-io) on the same IOLAN, remote IOLAN(s), and/or TCP/IP applications running
on local hosts.
set iochannel <channel> ioextension enabled on|off
[keepalive on|off]
set iochannel <channel> ioextension connection-method
client-initiated [tcp-port <tcp_port>] [multihost on|off]
set iochannel <channel> ioextension connection-method
server-initiated <host_name> [tcp-port <tcp_port>]
[multihost all|backup <config_backup_host> <host_port>|none]
set iochannel <channel> ioextension connection-method
local-connection [<input_channel>]
<channel>
Specify the Digital/Relay channel or serial signal pin that you are configuring the I/O
extension for. The channel can be d1, d2, d3, d4, r1, r2, depending on the model. The
serial signal pins are dsr, dcd, or cts for input and dtr or rts for output.
IOLAN SDS/SCS/STS CLI Reference Guide, Version 3.6
Manually
Trigger Type
Trigger Type is Low ).
Level Critical
Level Critical .
cleared, or can be cleared when
is High ) or goes above
and
Type
Line Email
.
