Set Line
Set IO Failsafe
Description Sets the failsafe (watchdog) settings for I/O.
User Level Admin
Syntax
Options
Set IO Modbus
Description Enabling the Modbus option makes the IOLAN act as a Modbus Slave, allowing
User Level Admin
Syntax
Options
Set IO Temperature-Scale
Description Sets the temperature scale that will be used for all I/O temperature readings.
User Level Admin
Syntax
Option
Set Line
Set Line Service
Description Sets the
User Level Admin
Syntax
Option
138
set io failsafe [mode on|off] [timeout <seconds>]
mode
Enables/disables the Failsafe Timer. This is the global setting that must be enabled to
set the Failsafe Action on the channel for digital outputs and relays. When this timer
expires because of no I/O activity within the specified time interval, the Failsafe Action
set for the channel determines the action on the output.
timeout
The number of seconds that must elapse with no I/O activity before the channel
Failsafe Action is triggered. Valid values are 1-9999. The default is 30 seconds.
Modbus Masters to communicate with the IOLAN to control and/or retrieve I/O data.
set io modbus [mode on|off] [uid <1-255>]
mode
Enables/disables Modbus as the communication protocol for all the I/O channels.
uid
This is the UID you are assigning to the IOLAN, which is acting as a Modbus slave.
set io temperature-scale celsius|fahrenheit
temperature-scale
Select the temperature scale that will be used to display temperature data, either
Fahrenheit or Celsius. The default is Celsius.
settings for signal I/O. When the line service is set to signal-io,
Line Service
you also have the option of enabling the I/O extension for the serial singal pins. See
IOChannel IOExtension on page 148
set line <number> service signal-io
signal-io
Sets the line to use signal I/O. You still need to define the serial pins for digital input
(CTS, DSR, or DCD) or digital output (RTS or DTR). See
Input (Serial Pins) on page 141
page 143
for configuration options.
IOLAN SDS/SCS/STS CLI Reference Guide, Version 3.6
for more information.
or
Set IOChannel Digital Output (Serial Pins) on
Set
Set IOChannel Digital
